Seagull Models YAK 54 Assembly Manual page 4

YAK 54
3.
4.
5.
Press the aileron and wing together such
that less than a 1/64" hinge line gap exists
between the aileron and wing. he bevels
should virtually touch. Use a paper towel
and rubbing alcohol to wipe away any
visible epoxy around the hinges.
6.
4
Epoxy
Epoxy
Hinge
Instruction Manual.
Allow the glue to fully cure for at least 6
hours.
When fully cured, move each control
surface throughout is travel range server-
al times to break away any epoxy in the
hinge. Be sure to delect the surface fully.
7.
8.
9.
Note : Work the aileron up and down sev
eral times to "work in" the hinges and check
for proper movement.
