Norstar Modular ICS 5.0 Companion Installer's Manual page 17

12-port Expansion Cartridge with Companion
Note 1: Station modules 13 and 14
are used for Companion
capability only. See your Norstar
Companion Installer Guide for
more detail.
Note 2: Using a 2 or 3 row layout is
acceptable. The layout depends
on the available wall space.
P0941568 01
SM6 SM5
Fiber Cable Guide
ICS (modules 1 and 2)
SM14 SM13
Planning the installation / 11
SM4 SM3
(max. 7 modules per power bar)
TM8 TM7
(max. 7 modules per power bar)
SM12 SM11 SM10
Modular ICS 5.0 Companion Installer Guide
To Ac
outlet
To Ac
outlet
SM9
