Planning the installation

Planning checklist

Œ
Verify that you have approval from UTAM Inc.
(U.S. only)
Œ
Verify that a site planner determined base station locations
and recorded them in the Provisioning Record.

Required equipment and supplies

Œ
Companion portable telephones
Œ
Companion base stations
Œ
Companion Remote Power Interconnect device or plug top
Power Supplies
Œ
Companion ID Labels (See Step 1: Obtain the Companion
ID on page 65.)

Configuring Station Modules

When installing wireless capabilities, use only the last two. or
highest numbered. ports for connecting the Companion base
stations.
Each Station Module allows you to connect up to 16 additional
Norstar telephones to the system.
Maximum number of Norstar telephones on a system
mini midi
ICS SM3 SM4
32 48 64
Each Station Module that is used for Norstar Companion
allows you to connect up to 16 base stations to the system.
P0941568 01
maxi
SM5 SM6 SM7
80 96 112
mega
SM8 SM9 SM10
128 144 160
Modular ICS 5.0 Companion Installer Guide
SM11 SM12
176 192
