Output Settings

Set output resolution and output window size.
Resolution
Horizontal Width
Vertical Height
Horizontal Start
Vertical Start
Display
Custom Resolution
Note: the steps of output settings for LED display:
1) Choose a suitable resolution (the number of horizontal pixels and vertical
pixels of the selected resolution are greater than that of the LED display) → Set
"H-Width" and "V-Height" according to the size of the LED display;
2) Horizontal start and vertical start are the same as the horizontal and vertical
start of sending card. Generally, they are set to 0;
3) Full/Part: It is part display by default after the width and height are set, that is,
zoomed-out picture will be shown on LED display; When full display is
selected, the output image, the size of which is the resolution selected, may be
beyond the screen;
4) Custom resolution: Max. output of a single unit is 2048×1152. It allows to set
resolution manually as required according to the corresponding sending card.

PIP

Channel2 picture, it allows to display in any position and any size.
PIP
CH2 signal source
Layer
Diaphaneity
Horizontal Width
Vertical Height
Horizontal Start
Vertical Start
Text Overlay
VX200 User's Manual
1280*1024@60Hz
1920
1080
0
0
Full/Part
>>
Open/Close
AV1/AV2//VGA/DVI/HDMI/USB
Top/Bottom Layer
0~15
1920
1080
0
0
>>
