The channel, position, size, diaphaneity of PIP can be set in this option.
Text Overlay: Text can be displayed in PIP.
Text Overlay
Preset
Blend Level
Preset: White On Black, Black On White, Green On Black, Green On White, Red On
Black, Red On White. When applying Text Overlay, choose CH2 signal source and
preset the corresponding characters and background.
Note: PIP is restricted to signal channels, as shown in the table below:
"√"denotes PIP can be opened; "×"denotes PIP cannot be opened.
PIP
Source

Image Crop

Image crop can be applied to CH1 and CH2;
Open "Image Crop" and set parameters. Then the cropped image will be shown
on LED display.
Image Crop
Horizontal Width
Vertical Height
Horizontal Start
Vertical Start
Note: Image crop is only for the input Channel and it will not affect the output of
other channels after the signal source is switched.
Image crop parameter settings:
VX200 User's Manual
Open/Close
White On Black
0~15
Main Channel Source
HDMI
HDMI
DVI ×
VGA √
AV1 √
AV2 √
USB √
Open/Close
1920
1080
0
0
DVI VGA AV1
× √ √
√ √
√ √
√ √
√ √ ×
√ √ √
-9-
AV2 USB
√ √
√ √
√ √
× √
√
√
