Electrical Parameters - NovaStar VX200 User Manual

Electrical Parameters

Input/Output interface and performance index of the processor:
Inputs
Port Qty
AV 2
USB 1
VGA 1
DVI 1
HDMI 1
Outputs
Port Qty Resolution Specifications
640×480@60Hz, 1024×768@60 Hz, 1280×720@60Hz,
1280×768@60Hz, 1280×800@60Hz, 1280×1024@60Hz,
1366×768@60Hz, 1440×900@60Hz, 1536×1536@60Hz,
1600×1200@60Hz, 1680×1050@60Hz, 1920×1080@60Hz,
DVI 2
1920×1200@60Hz, 2048×640@60Hz, 2048×1152@60Hz ,
2560×816@60Hz, 1920×1080@50Hz,
1024×768@75/85/100/120 Hz, 1280×1024@75/85/100Hz
Custom resolution
Control
Port Qty
USB 1
Overall Specifications
Input power
Overall power consumption
Operating temperature
Dimensions
Weight
VX200 User's Manual
Resolution Specifications
PAL/NTSC
Standard USB2.0 interface
VESA standard, Max. supported input 1080p@60Hz
VESA standard (supports 1080i input), supports HDCP
EIA/CEA-861 standard, in accordance with HDMI-1.3
standard, supports HDCP
Notes
Control interface of upper computer
AC 100-240V, 50/60Hz
25W
0~45℃
482.6×275×44.5（mm）
2.55 Kg
-4-
