8030 Pressure Controller/Calibrator

1.3 8030 Front Panel

The front panel features a 7" TFT touchscreen, to display controls and instrument information.

1.4 8030 Rear Panel

Note: Pressure fittings supplied not shown below.
RS-232 port
Ref
Ports
Test
Port
8030 Pressure Controller/Calibrator
Vacuum Vent
Port Port
USB
Supply Mains supply and
Port power switch
User Manual
v1.1
Ethernet
