Summary of Contents for Steelcase IMPACT Bullet Desk
- Page 2 Y9501952 Rev. E Page 2 of 4 Steelcase...
- Page 3 Attach (2) Z-brackets to bottom of worksurface. Lower assembled panels into place. TOP VIEW Secure all brackets with screws provided. (2) Screws (4) Screws per bracket per bracket 10-12 x 3/4” 10-12 x 3/4” Pan Head Pan Head Y9501952 Rev. E Page 3 of 4 Steelcase...
- Page 4 (12) screws #10-9 X 1 3/4” truss head Y9501952 Rev. E Page 4 of 4 Steelcase...
