103781301
If you have a problem, question, or request, call
your local dealer, or Steelcase Line 1 at
888.STEELCASE (888.783.3522)
for immediate action by people who want to help you.
(Outside the U.S.A., Canada, Mexico, Puerto Rico,
and the U.S. Virgin Islands, call: 1.616.247.2500)
Or visit our website: www.steelcase.com
©
2016 Steelcase Inc.
Grand Rapids, MI 49501
U.S.A.
Printed in U.S.A.
Ology
Rectangular & Tapered Desks - Base Only
This equipment has been tested and found to comply with the limits for a class B digital device pursuant
to Part 15 for FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures: Reorient or relocate the receiving antenna. Increase the
separation between the equipment and receiver. Connect the equipment into an outlet or a circuit different
from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician
for help.
This class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada
3, 5 & 6MM
#2
10MM
3, 5 & 6MM
TORQUE
WRENCH
Page 1 of 39
103781301 Rev K

Advertisement

loading
Need help?

Need help?

Do you have a question about the Ology Rectangular Desk and is the answer not in the manual?

Questions and answers

Summary of Contents for Steelcase Ology Rectangular Desk

  • Page 1 If you have a problem, question, or request, call interference in a residential installation. This equipment generates, uses and can radiate radio frequency your local dealer, or Steelcase Line 1 at energy and, if not installed and used in accordance with the instructions, may cause harmful interference TORQUE 888.STEELCASE (888.783.3522)
  • Page 2: Important Safety Instructions

    4. Never operate this table if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water. If the cord is damaged, have it replaced by a Steelcase dealer.
  • Page 3: Conservez Ces Directives

    Nunca use esta mesa si tiene un cable o enchufe dañado, si no está funcionando correctamente, si se ha caído o dañado, o si se le ha dejado caer en el agua. Si el cable está dañado,...
  • Page 4 BASES-ONLY WARRANTY LIMITATIONS AND POTENTIAL FOR INJURY: The use of worksurfaces worksurfaces can pinch and that do not comply with the Steelcase defined criteria and limitations could cause personal injury or cause injury or property damage. property damage due to pinch points, instability, or other problems, and VOIDS all Steelcase warranties, Always follow these instructions: expressed or implied.
  • Page 5 RISK OF SERIOUS INJURY DUE TO PINCH POINTS, TIPOVER, OR POTENTIAL COLLAPSE. All worksurfaces (provided by Steelcase or by customer) must meet all of the requirements for fasteners, clearance, and dimensional limits as follows: FASTENERS: Adjustable-height bases include fasteners intended for use with Steelcase worksurfaces.
  • Page 6 ANSI/BIFMA, UL, LEED et avec toutes autres exigences applicables. L'utilisation de l'écart de tout obstacle, au-dessus et dessous la surfaces de travail non fabriquées par Steelcase avec les bases à hauteur réglable de surface de travail Steelcase pourrait NE PAS être considérée comme conforme aux codes de l'électricité...
  • Page 7: Éléments De Fixation

    ÉLÉMENTS DE FIXATION : Les bases à hauteur réglable comprennent des éléments de fixation conçus pour les surfaces de travail Steelcase. Ces éléments de fixation PEUVENT aussi convenir aux surfaces de travail conformes aux critères suivants: bres de densité...
  • Page 8 OSHA para lugares de 2. Planee tener un espacio de 1 pulgada mínima trabajo, porque este uso no crea un producto listado en NRTL (UL, ETL, etc.). Steelcase no es contra una pared o panel.
  • Page 9 RIESGO DE LESIONES GRAVES DEBIDO A PUNTOS DE PELLIZCO, VUELCOS, O POSIBLE COLAPSO. Todas las superficies de trabajo (proporcionadas por Steelcase o por el cliente) deben cumplir con todos los requisitos para sujetadores, despeje y límites dimensionales como se indica abajo: SUJETADORES: Las bases con altura ajustable incluyen sujetadores destinados a ser usados con las superficies de trabajo Steelcase.
  • Page 10 Page 10 of 39 103781301 Rev K...
  • Page 11 Page 11 of 39 103781301 Rev K...
  • Page 12 Page 12 of 39 103781301 Rev K...
  • Page 13 Page 13 of 39 103781301 Rev K...
  • Page 14 Page 14 of 39 103781301 Rev K...
  • Page 15 Page 15 of 39 103781301 Rev K...
  • Page 16 Page 16 of 39 103781301 Rev K...
  • Page 17 Page 07 of 39 103781301 Rev K...
  • Page 18 Page 18 of 39 103781301 Rev K...
  • Page 19 Page 19 of 39 103781301 Rev K...
  • Page 20 Page 20 of 39 103781301 Rev K...
  • Page 21 Page 21 of 39 103781301 Rev K...
  • Page 22 Page 22 of 39 103781301 Rev K...
  • Page 23 Page 23 of 39 103781301 Rev K...
  • Page 24 ® 35” 23” 29” Page 24 of 39 103781301 Rev K...
  • Page 25 ® NOTE: Attach one leg only 35” 23” 29” NOTE: Thicker edgeband is front of worksurface. Page 25 of 39 103781301 Rev K...
  • Page 26 ® Loosen Bolts Longer cable - 2 M Tube Orientation: Hole on tube can be placed on the Left or Right Hand side depending on User Preference. Hole on tube can face front or back. Place towards back if there is no Cable Tray or Basket.
  • Page 27 ® 11 4X 6mm Hex 25 Nm (221 in-lbs) Page 27 of 39 103781301 Rev K...
  • Page 28 ® Placement of Control Box ______________________ If you have a Cable Basket or Power Access Door in the Back, place Control Box in the Front of the Frame Tube. Otherwise, place the Control Box behind the Frame Tube for best knee clearance. Place Control Box on the same side as the desired User Switch location (Left or Right).
  • Page 29 ® Route and make cable connections To Strain Relief Power Cord Page 29 of 39 103781301 Rev K...
  • Page 30 ® For 4 Preset Only 4 Preset Active & Simple Touch NOTE: Gasket for Simple Touch Only. Page 30 of 39 See Arrow for correct orientation. 103781301 Rev K...
  • Page 31 ® Press down to initialize the desk, holding for 3 seconds. After initialization, the legs will now adjust vertically. For Active Touch Only: Tap the Switch. Each time it is pressed, it will toggle between 22.6" and 27.3", the 2 different Extended Leg: 22.6"...
  • Page 32 ® 1a 2X 1b 4X Rail Option: (If Applicable) Page 32 of 39 103781301 Rev K...
  • Page 33 ® 228mm < = (9 inches) Page 33 of 39 103781301 Rev K...
  • Page 34 ® Page 34 of 39 103781301 Rev K...
  • Page 35 ® Rail Access Door Option: (If Applicable) Page 35 of 39 103781301 Rev K...
  • Page 36 ® Page 36 of 39 103781301 Rev K...
  • Page 37 ® Grommet Option: (If Applicable) Page 37 of 39 103781301 Rev K...
  • Page 38 ® Page 38 of 39 103781301 Rev K...
  • Page 39 ® Page 39 of 39 103781301 Rev K...

This manual is also suitable for:

Ology tapered desk
