Steelcase Elective Elements Fixed Modesty Panel Manual page 2

INSET MODESTY PANEL
1.
Turn worksurface over onto a clean,
soft surface.
2.
Locate holes in pedestal end panels
and drill through.
3.
Install pedestals onto worksurface
as shown. For more details, refer to
assembly direction 939500237.
Locate (2) pilot holes
in each pedestal, then
drill them through.
Align pedestals flush with
front and sides of worksurface.
2
3
(4) screws per pedestal
through holes in stretchers,
1-1/2" pan head
Page 2 of 10
P/N 939500227
Doc # 108322 Rev J
