Steelcase Context Assembly Directions

International base power-in with circuit breakers

Steelcase, Inc.

Grand Rapids, MI 49501

U.S.A.

1-888-783-3522

This assembly direction shows installation of the Base Power-in into a utility trunk,

boundary wall is typical.

IMPORTANT: Do not assemble this product until you have read the supplementary Assembly

Directions outlining specifications and safety standards necessary to the safe use for this product.

This power system must be earthed (grounded)!

Tools

Assembly Directions

Context

International Base Power-In

(With Circuit Breakers)

All electrical installations should be done by a

qualified person in accordance with codes and

regulations applicable at the installation site.

Printed In U.S.A.

REV

93-9504014 A

Page 1 of 4

Table of Contents

Need help?

Do you have a question about the Context and is the answer not in the manual?

Page 1 Steelcase, Inc. Grand Rapids, MI 49501 U.S.A. 1-888-783-3522 ® Context International Base Power-In (With Circuit Breakers) This assembly direction shows installation of the Base Power-in into a utility trunk, boundary wall is typical. IMPORTANT: Do not assemble this product until you have read the supplementary Assembly Directions outlining specifications and safety standards necessary to the safe use for this product.
Page 2 Remove access plate. ACCESS PLATE Remove closure plate from access plate. CLOSURE PLATE ACCESS PLATE Attach base power-in mounting bracket to receptacle mounting bracket. BASE POWER-IN MOUNTING BRACKET SERRATED PAN HEAD TAPPING SCREWS (2) BLUNT TIP Assembly Directions Page 93-9504014 REV A 2 of 4...
Page 3 Position access plate. Do not attach at this time! Thread base Power Distribution Block Legend power- in extender cables through receptacle opening, and connect to power distribution blocks. (See power distribution legend ) Block Color Circuit Black Power POWER DISTRIBUTION BLOCKS Blue Power...
Page 4 Assemble base power-in cover. SERRATED PAN HEAD TAPPING SCREWS (2) BLUNT TIP BASE POWER-IN COVER Connect base power-in cord sets to building power supply. IMPORTANT: Base power-in cordsets are color coded with tape according to their circuit usage. (see legend in step 4.) They must be plugged directly into the building power supply.
