Tools Required

10-4-1

Standard GE Tool Kit

The following is a description of the "Standard" GE tool kit in the USA. Not all tools are required for PMs.
Table 10-3
Tool ID
9-45358
9-4078
9-44572
9-44579
9-44579
9-45385
9-45378
9-4518
9-4518
9-44776
9-44601
9-4151
9-41421
9-41594
9-41581
9-39451
9-GH807
68-412
9-GH130
9-41584
9-4118
9-41293
9-41294
9-41295
9-46677
9-34701
9-43499
9-4355
9-43523
9-43531
10 - 4
10
EVISION
Overview of GE-1 Tool Kit Contents
Description
Pliers Retaining Ring
Scribe
Wrench Open End 3/8 - 7/16
Wrench Open End 1/2 - 9/16
Wrench Open End 1/2 - 9/16
Pliers, Arc Joint 7 inch
Pliers, Slip Joint
Pliers, Long Nose, Miniature
Pliers, Long Nose, Miniature
Ignition Wrench Set, 10 pc.
Wrench, Adj., 4 inch
Screwdriver, Blade, Stubby
Screwdriver, Blade, Pocket clip
Screwdriver, Blade 1/8 in. x 4 in.
Screwdriver, Blade 3/16 in. x 4 in.
20' Steel Tape, locking Spring load
Ratchet, Offset, Slotted
Ratchet, Offset, Phillips
Tapered Reamer
Screwdriver, slotted 1/4 in.X 6 in.
Screwdriver, Phillips #2, Stubby
Screwdriver, Phillips #0
Screwdriver, Phillips #1
Screwdriver, Phillips #2
Hex Keys, 20 pc., Metric
1/4 in. Standard.Socket set (19 pc)
1/2 inch Socket 1/4 inch drive
Flex Spinner
Breaker
6 inch Ext.
Section 10-4 - Tools Required
Tool ID
9-XL9971MM Xcelite-hex Blade 1.27mm
9-XL9972MM Xcelite-hex Blade 1.5mm
9-XL9973MM Xcelite-hex Blade 2 mm
9-XL9974MM Xcelite-hex Blade 2.5mm
9-XL9975MM Xcelite-hex Blade 3mm
9-XL9976MM Xcelite-hex Blade 4mm
9-XL9977MM Xcelite-hex Blade 5mm
9-XL991CM Handle
C2356E Screw starter - Kedman Quick Wedge
BLBO Box - 18 Compartment
DWL4283T Box - 5 Compartment
9-41322 Pickup Tool, Claw type
9-6757 6 pc Needle File Set
9-9487 Utility Knife
9-45341 Pliers Vice Grip 10 inch
9-3001 Xacto Pen Knife
9-HT62002 Solder Aid, Fork and Hook
9-4099 Mirror, Round, Telescoping
9-GH3001 Steel Rule Decimal 6 inch
9-GH300ME Steel Rule Metric 6 inch
9-XL9920 Xcelite-hex Blade.050 inch
9-XL9921 Xcelite-hex Blade 1/16 inch
9-XL9922 Xcelite-hex Blade 5/16 inch
9-XL9923 Xcelite-hex Blade 3/32 inch
9-XL9924 Xcelite-hex Blade 1/8 inch
9-XL9925 Xcelite-hex Blade 5/32 inch
9-XL9926 Xcelite-hex Blade 3/16 inch
9-XL99764 Xcelite-hex Blade 7/64
9-XL99964 Xcelite-hex Blade 9/64
9-XLM60 Mini-screwdriver kit
