Command and data value descriptions

7.3.23 D_VIFC_VERSION

This data value represents the software version of the VIFC.
Value Description
Data3 Minor version
Data4 Major version

7.3.24 D_VIFC_IMC_ALIVE

This data value represents the "Alive" state of the IMC.
Value
Running
The IMC is up and running with no errors:
• Initialization
0 • Idle
• Insulation warning
• Self test
• Calibration
Error
The IMC is up and running but has detected an error:
1 • System failure
• Insulation fault
• Chassis fault
Performance error
2 The VIFC has received the analogue "Alive" signal but was
not able to evaluate it correctly.
Unknown
100 The VIFC is not receiving the analogue "Alive" signal from the
IMC.
24
Description
Command and data value descriptions

7.3.25 D_VIFC_STATUS

This data value represents the status state of the VIFC.
Bit Description
0 Insulation measurement
1 IMC connectivity*)
2 IMC "Alive" status detection
3 Reserved
4 VIFC command*)
5 Reserved
6 Reserved
7 Reserved
8 Insulation resistance value
9 Reserved
10 Reserved
11 Reserved
IMC self test
12
(OverAll scenario)
IMC self test
13
(ParameterConfig scenario)
14 Reserved
15 Reserved
*) Currently not implemented
Status
0 = Activated
1 = Deactivated
0 = OK
1 = Failure
0 = OK
1 = Failure
0 = NoError
1 = Error
0 = Valid
1 = Outdated
0 = Executed
1 = NotExecuted
0 = Executed
1 = NotExecuted
