Command and data value descriptions

7.3.3 D_IMC_R_ISO_WRN_THR

This data value represents the threshold that causes an insulation warning when the in-
sulation resistance is lower than this value.
Unit kΩ
300 (for iso165C)
Default
400 (for iso165C-1)
Resolution 1
Range 40...2,000

7.3.4 D_IMC_MEAN_FACTOR

This data value represents the mean factor of the insulation resistance averaging
algorithm.
Unit Number of measurements
Default 3
Resolution 1
Range 1...20

7.3.5 D_IMC_STATUS

This data value represents the internal status of the IMC.
Bit Description
0 Insulation fault
1 Chassis fault
2 System failure
3 Calibration running
4 Self test running
5 Insulation warning
6 Reserved
7 Reserved
8 Reserved
9 Reserved
10 Reserved
11 Reserved
21
Status
0 = NoError
1 = Error
0 = NoError
1 = Error
0 = NoError
1 = Error
0 = NotRunning
1 = Running
0 = NotRunning
1 = Running
0 = NoWarning
1 = Warning
Command and data value descriptions
Bit Description
12 Reserved
13 Reserved
14 Reserved
15 Reserved

7.3.6 D_IMC_STATUS_EXT

This data value represents device-internal IMC self-test results.
Bit Description
0 Calibration parameter
1 Hardware failure
2 EEPROM parameter
3 FLASH parameter
4 RAM Parameter
5 Stack overflow
6 Reserved
7 Parameter value
8 Test pulse voltage/ARef
9 Voltage level (+12 V)
10 Voltage level for -12V
11 FuseBits valid/invalid
12 HV1 voltage
13 HV2 voltage
14 Manufacturer string valid/invalid
15 Reserved
Status
Status
0 = NoError
1 = Error
0 = NoError
1 = Error
0 = NoError
1 = Error
0 = NoError
1 = Error
0 = NoError
1 = Error
0 = NoError
1 = Overflow
0 = NoError
1 = Error
0 = NoError
1 = Error
0 = NoError
1 = Error
0 = NoError
1 = Error
0 = NoError
1 = Error
0 = NoError
1 = Error
0 = NoError
1 = Error
0 = NoError
1 = Error
iso165C_D00154_03_M_XXEN/01.2019
