3 - MagneFlex Powder Resources
Parameter
CardType
ConfirmationWaitTime
PINEntryWaitTime
Tones
Options
TransactionType
Amount
CashBack
Reserved
AdditionalRequestData
CloseDevice
SDK - MagneFlex Powder, MIddleware,| PIN PEDs | Programmer's Manual (MagneFlex API)
Page 24
Card type that can be used for the transaction:
1 = Magnetic stripe
2 = Contact smart card
3 = Magnetic stripe or contact smart card
4 = Contactless smart card (Not supported on DynaPro Mini)
5 = Contactless smart card + magnetic stripe
6 = Contactless smart card + contact smart card
7 = Magnetic stripe + contact smart card + contactless smart card.
Time the device will wait for the user to begin the transaction.
Time the device will wait for the user to enter the PIN.
Tones to use:
0 = No sound
1 = One beep
2 = Two beeps
Transaction options:
0 = Normal
1 = Bypass PIN
2 = Force Online
4 = Acquirer not available
Type of transaction to be used:
0x02 = Cash back
0x04 = Goods
0x08 = Services
The amount to be used and authorized in decimal format.
1.01 = 1 dollar and 1 cent
The amount of cashback to be used and authorized in decimal format.
1.01 = 1 dollar and 1 cent
Reserved for future use. These are the reserved bytes begining at index 20
of the 0xA2 command. Reference device manual D99875585 for more
details.
Example:
0000000000000000000000000840000100 – QuickDip Mode
0000000000000000000000000840000003 – PIN Verify
0000000000000000000000000840000004 – PIN Set
Additional key/value pairs of data
Flag which determines whether the connection to the device will be closed
after the request is processed. Default value is "false".
"false" = Do no close the device.
"true" = Close device.
Description
