Bath Screen
INSTALLATION INSTRUCTIONS
www.aquadart.co.uk
www.aprilproducts.co.uk
www.aprilproducts.co.uk
Item Number:AQ6000/AQ6001
Tools Required
6
2.75
PH2 TYPE
IMPORTANT
This product should be installed by a suitably qualified and proficient person. The fitting instructions should be
followed carefully to ensure a proper and safe installation. Failure to follow these instructions could result in future
injury.
These instructions and list of parts assume that installation is done against solid/tiled walls.
Please check this product for damage prior to starting the installation. No claims can be made after the product has
been fitted.
PLEASE NOTE :The minimum and maximum adjustment sizes noted on the product brochures are based on
perfectly plumb walls and trays.
USE SAFETY EYE-WEAR WHEN DRILLING
