Mini Bath Screen
INSTALLATION INSTRUCTIONS
www.aquadart.co.uk
www.aprilproducts.co.uk
www.aprilproducts.co.uk
Tools Required
6
2.75
PH2 TYPE
IMPORTANT
This product should be installed by a suitably qualified and proficient person. The fitting instructions should be
followed carefully to ensure a proper and safe installation. Failure to follow these instructions could result in future
injury.
These instructions and list of parts assume that installation is done against solid/tiled walls.
Please check this product for damage prior to starting the installation. No claims can be made after the product has
been fitted.
PLEASE NOTE :The minimum and maximum adjustment sizes noted on the product brochures are based on
perfectly plumb walls and trays.
USE SAFETY EYE-WEAR WHEN DRILLING
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Aquadart Venturi 6 AP9575
Summary of Contents for Aquadart Venturi 6 AP9575
- Page 1 Mini Bath Screen INSTALLATION INSTRUCTIONS www.aquadart.co.uk www.aprilproducts.co.uk www.aprilproducts.co.uk Tools Required 2.75 PH2 TYPE IMPORTANT This product should be installed by a suitably qualified and proficient person. The fitting instructions should be followed carefully to ensure a proper and safe installation. Failure to follow these instructions could result in future injury.
- Page 2 IMPORTANT - Missing Components Please check this product for missing components prior to installation. For spare parts visit www.aquadart.co.uk IMPORTANT - Installation site 1. Ensure the top surface of the bath on which the enclosure will be installed is level in every direction.
- Page 3 Ф 6 drill bit Ф2.75 drill bit Step 1: Position the wall profile (1) onto the bath , approximately 12-15mm from the outside bath edge to ensure that the screen runs along the inside edge of the bath rim. (A). Step 2: Level the profile with a spirit level , then mark the position using a pencil.
- Page 4 Allow 24 hours before use for silicone to set . For cleaning instructions see guarantee .
- Page 5 Riverside Business Park,Royd Ings Avenue,Keighley, West Yorkshire,BD21 4AF 01535 613830 Technical:01535 613830 Fax: 01535 613831...
