Technical data and installation

Technical Features

Installation

SMART CLEARER Terminal
Power supply voltage
Maximum Absorption
Dimensions
Temperature range
LCD graphic Display
Integrated Touch-pad
Protection
ISSC.. Sensors
Power supply voltage
Absorption
ENABLE input logic
STOP output
STOP output logic
"Auto-calibration" function
STOP output protection
STOP output max current
Activation delay
Signaling
Dimensions
Temperature range
The installation of the SMART CLEARER system depends on the type of
application and on the number of sensors to be connected. When the number of
sensors is limited, it is possible to connect them directly to the SMART terminal,
otherwise it is necessary to use a stabilized power supply PSU 10A. This is
capable of supplying up to 8 independent backbone lines to which it is possible to
connect several sensor chains (up to a maximum of 100 sensors). The number of
sensors may be extended to 200, using two PSU 10A power supply.
SMART CLEARER
2 2 2 2 – – – – TECHNICAL DATA AND INSTALLATION TECHNICAL DATA AND INSTALLATION
TECHNICAL DATA AND INSTALLATION TECHNICAL DATA AND INSTALLATION
24 Vdc ± 10%
100 mA
135 x 95 x 40 mm
10° - 60 °C
80 x 40 mm
5 membrane buttons with integrated red LED
2 fuses 5 x 20 – 1A
12 .. 24 Vdc ± 20%
30 mA (max 50 mA)
Programmable (NO - NC)
NPN open collector
Programmable (NO - NC) (cont. – pulse, 2sec.)
Auto-calibration of sensor
Protection against over-voltages and short-circuits
200 mA continuous; 500 mA peak
Programmable from 1 to 250 sec
With integrated LED
15 x 15 x 36,5
10° - 50 °C
- 2.1 -
