Transport Series
720 Transport Stretcher
Maintenance Manual
For Parts or Technical Assistance
800−327−0770

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 720 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Stryker Medical 720

Summary of Contents for Stryker Medical 720

  • Page 1 Transport Series 720 Transport Stretcher Maintenance Manual For Parts or Technical Assistance 800−327−0770...

  • Page 2: Table Of Contents

    Table of Contents Introduction Specifications ................Warning / Caution / Note Definition .
  • Page 3 Table of Contents Assembly Drawings and Parts Lists (Continued) Long Transfer System Assembly, Right ........... Removable I.V.

  • Page 4: Introduction

    Introduction INTRODUCTION This manual is designed to assist you with the maintenance of the Model 720 Transport Stretcher. Read it thoroughly before using the equipment or beginning any maintenance on it. SPECIFICATIONS Maximum Weight Capacity 500 pounds Overall Bed Length/Width 81”, 30”...

  • Page 5: Preventative Maintenance Checklist

    Preventative maintenance should be performed at a minimum of annually. A preventative maintenance pro- gram should be established for all Stryker Medical equipment. Preventative maintenance may need to be performed more frequently based on the usage level of the product.

  • Page 6: Cleaning

    Cleaning Hand wash all surfaces of the stretcher with warm water and mild detergent. Dry thoroughly. DO NOT STEAM CLEAN, PRESSURE WASH, HOSE OFF OR ULTRASONICALLY CLEAN. Using these methods of cleaning is not recommended and may void this product’s warranty. Clean Velcro AFTER EACH USE.

  • Page 7: Service Information

    Service Information CASTER COVER INSTALLATION AND REMOVAL Double Prongs Looking through the larger of the two side cut−outs, align the cover with the axle nut or bolt head, as shown. Single Prong Push down on the opposite side of the cover until the single prong engages the caster horn.

  • Page 8: Brake Rod Removal

    Service Information BRAKE ROD REMOVAL Required Tools: Hammer 7/32” Punch String or Bungee Cords 1. Pump the litter up to full height. 2. Lift the base hood and support it from the litter using string or bungee cords. 3. Remove the hex head cap screws connecting the brake rod supports to the base frame. 4.

  • Page 9: Brake Ring Removal

    Service Information BRAKE RING REMOVAL Required Tools: 9/16” Socket w/Extension 3/8” Drive Ratchet Needle−Nose Pliers String or Bungee Cord 1. Pump the litter up to full height. 2. Lift the base hood and support it from the litter using string or bungee cords. 3.

  • Page 10: Stretcher Height Adjustment

    STRETCHER HEIGHT ADJUSTMENT NOTE The 720 Transport Stretcher is available in three ”fixed” heights: 28”, 30”, and 32”. The preset stretcher height was chosen at the time of purchase. Follow the procedure below to change the stretcher height. Required Tools: 1/2”...

  • Page 11: Siderail Latch Adjustment

    Service Information SIDERAIL LATCH ADJUSTMENT Required Tools: 1/8” Hex Allen Wrench WARNING The siderail latches are preset at the factory, and do not normally need adjustment. If adjustment must be done, it is important to follow the procedure below. If adjustment is not done properly, injury to the patient or user could occur.

  • Page 12: Replacement Parts

    Replacement Parts and Kits PART NAME PART NUMBER Caster Assembly (1 complete) ..........0753−010−020 Caster Cover Kit .
  • Page 13 Replacement Parts and Kits Restraint Straps, Complete Set ..........1010−077−000 Restraint Straps, Ankle .
  • Page 14 Fixed Height Base Assembly with Standard Brakes Assembly part number 0720−600−210 (reference only) 0720−133−025 0720−660−021 0720−665−022 0720−800−030 Item Part No. Part Name Qty. 0023−288−000 Hex Washer Hd, Screw 0023−305−000 Hex Washer Hd, Screw (page 14) Standard Brake Assembly (page 18) Fifth Wheel Assembly 0753−006−148 Cam Bearing...
  • Page 15 Base Assembly w/Standard Brakes (Fifth Wheel Base) Assembly part number 0753−003−005 (reference only)
  • Page 16 Base Assembly w/Standard Brakes (Fifth Wheel Base) Item Part No. Part Name Qty. 0005−039−000 Step Bolt 0011−262−000 Washer 0016−035−000 Nylock Hex Nut 0016−049−000 Nylock Hex Nut 0023−288−000 Hex Washer Hd. Screw 0027−012−000 Hitch Pin 0028−037−000 External Retaining Ring 0038−439−000 Extension Spring 0081−272−000 Roller Bearing 0753−001−001...

  • Page 17: Brake Rod Assembly

    Brake Rod Assembly Assembly part number 0753−003−001 (reference only) Item Part No. Part Name Qty. 0026−067−000 Slotted Spring Pin 0753−003−004 Brake Rod Support (page 17) Drive Link Assembly 0753−003−014 Brake Rod 0753−003−015 Nyliner 0753−003−099 Butterfly “V” Pedal (page 17) Drive Link Assembly 1210−201−335 Red Brake Label 1210−201−336...

  • Page 18: Drive Link Assembly

    0753−003−010 Drive Link Assembly Item Part No. Part Name Qty. 0753−003−011 Brake Rod Drive Link 0753−003−061 Brake Cam Drive Link 0753−003−098 Flat Hd. Semi−Tubular Rivet 0753−003−102 Brake Cam 0753−006−135 Drive Link Assembly Item Part No. Part Name Qty. 0753−003−011 Brake Rod Drive Link 0753−003−098 Semi−Tubular Rivet 0753−006−122...

  • Page 19: Fifth Wheel Assembly

    0753−006−130 Fifth Wheel Assembly...
  • Page 20 0753−006−130 Fifth Wheel Assembly Item Part No. Part Name Qty. 0003−083−000 Hex Hd. Cap Screw 0016−035−000 Nylock Hex Nut 0023−288−000 Hex Washer Hd. Screw 0025−050−000 Rivet 0753−006−074 Torsion Spring 0753−006−075 Torsion Spring 0753−006−097 Drive Shaft Bearing 0753−006−106 Dampener 0753−006−108 Thrust Washer 0753−006−115 Bearing 0753−006−120...

  • Page 21: Caster Assembly

    0753−010−020 8” Caster Assembly Item Part No. Part Name Qty. 0715−002−025 Wheel 0003−099−000 Hex Hd. Cap Screw 0753−010−021 Caster Horn w/Bearing 0016−060−000 Centerlock Nut...
  • Page 22 Fixed Height Base Assembly with 4−Sided Brakes Assembly part number 0720−600−310 (reference only) 0720−133−025 Item Part No. Part Name Qty. 0023−288−000 Hex Washer Hd. Screw 0023−305−000 Hex Washer Hd. Screw (page 22) Side Control Brake Assembly (page 18) Fifth Wheel Assembly 0753−006−148 Cam Bearing 0753−010−007...
  • Page 23 Base Assembly with 4−Sided Brakes Assembly part number 0753−003−120 (reference only)
  • Page 24 Base Assembly with 4−Sided Brakes HEAD END FOOT END Item Part No. Part Name Qty. Item Part No. Part Name Qty. 0005−039−000 Step Bolt 0753−003−066 Clevis Pin 0011−262−000 Washer 0753−003−079 Brake Pin Guide 0016−035−000 Nylock Hex Nut (page 24) Side Brake Rod Ass’y 0016−049−000 Nylock Hex Nut 0753−003−121...
  • Page 25 0753−003−110 Side Control Brake Rod Assembly Item Part No. Part Name Qty. 0026−067−000 Slotted Spring Pin 0026−340−000 Clevis Pin 0027−020−000 Rue Ring Cotter 0753−003−099 Butterfly “V” Pedal 0753−003−112 Side Control Link 0753−003−114 Support Weldment 0753−003−117 Rod End Link 0753−003−119 Side Control Brake Rod 0753−005−044 Pedal Bushing 1210−201−335...
  • Page 26 Brake Rod Assembly Assembly part number 0753−003−125 (reference only) Item Part No. Part Name Qty. 0026−067−000 Slotted Spring Pin 0753−003−004 Brake Rod Support (page 17) Drive Link Assembly 0753−003−014 Brake Rod 0753−003−015 Brake Rod Nyliner 0753−003−099 Butterfly “V” Pedal 0753−003−112 Side Control Link (page 17) Drive Link Assembly...
  • Page 27 Base with Standard Brakes Labeling Assembly Department Label See Page 28 Specification Label HEAD END FOOT END Item Part No. Part Name Qty. 0753−010−046 Base Hood 0946−201−060 Stryker Logo Label 0946−421−005 Grommet Color Item D Brake/Steer Item E Brake/Steer Item F Side Stripe Litter Bumper Strip Set P/N Label, Foot End...
  • Page 28 Base with 4−Sided Brakes Labeling Assembly Department Label See Page 28 Specification Label HEAD END FOOT END Item Part No. Part Name Qty. 0753−010−047 Base Hood 0946−421−005 Grommet 0946−201−060 Stryker Logo Label 0753−010−018 Brake/Steer Label, Right 0753−010−019 Brake/Steer Label, Left Color Set Item F Brake/Steer Label,...
  • Page 29 Department Labels BASE HOOD DEPARTMENT LABELS Department Label Part Number Emergency 1010−900−215 PACU 1010−900−220 Transport 1010−900−225 Surgery 1010−900−230 Extended Stay 1010−900−235 Maternity 1010−900−240 Endoscopy 1010−900−245 Radiology 1010−900−250 Nuclear Medicine 1010−900−255 Ambulatory Surgery 1010−900−260 G.I. Lab 1010−900−265 Cath. Lab 1010−900−270 Same Day Surgery 1010−900−275 Cardio.

  • Page 30: Litter Assembly

    Litter Assembly Assembly part number 720−201−010 (reference only) HEAD END Detail of Foot Section Tube and Fasteners...
  • Page 31 Litter Assembly HEAD END...
  • Page 32 Litter Assembly Item Part No. Part Name Qty. Item Part No. Part Name Qty. 0721−201−020 Frame Assembly 0720−201−021 Riser Stop 0028−072−000 Retaining Ring 1001−034−025 End Plug 1001−040−012 Foot Board Receptacle 0014−002−000 Flat Washer 0023−104−000 Self−Tapping Screw 0003−047−000 Hex Hd. Cap Screw 0926−400−142 Corner Wheel 0027−004−000 Cotter Pin 1010−201−027 Bumper Extrusion...

  • Page 33: Manual Fowler Assembly

    Manual Fowler Assembly Assembly part number 0721−232−010 (reference only) HEAD END Item Part No. Part Name Qty. 0721−232−019 Brace Assembly 0014−002−000 Nylon Flat Washer 0003−357−000 Hex Hd. Cap Screw 0016−118−000 Nylock Hex Nut 0003−355−000 Hex Hd. Cap Screw 1001−032−022 Position Bar Rest 0004−135−000 But.

  • Page 34: Pneumatic Fowler Assembly

    Pneumatic Fowler Assembly Assembly part number 0721−231−110 (reference only) HEAD END Item Part No. Part Name Qty. 0004−182−000 Hex Soc. But. Hd. Cap Screw 0004−183−000 Hex Soc. But. Hd. Cap Screw 0011−179−000 Washer 0014−021−000 Washer 0015−060−000 Hex Jam Nut 0016−116−000 Hex Nut 0016−117−000 Hex Nut...
  • Page 35 Pneumatic Fowler Assembly Assembly part number 0721−231−120 (reference only) Item Part No. Part Name Qty. 0004−135−000 But Hd. Cap Screw 0004−161−000 Hex Soc. But. Hd. Cap Screw 0007−071−000 Truss Hd. Mach. Screw 0015−037−000 Jam Nut 0015−050−000 Hex Nut 0016−118−000 Stover Lock Nut 0021−125−000 Set Screw 0021−126−000...

  • Page 36: Outer Housing Assembly

    Pneumatic Fowler Outer Housing Assembly Assembly part number 1210−031−106 (Right) Item Part No. Part Name Qty. 0025−144−000 Semi−Tubular Rivet 1210−031−103 Pivot Tab 1210−031−104 Outer Housing, Right Assembly part number 1210−031−107 (Left) Item Part No. Part Name Qty. 0025−144−000 Semi−Tubular Rivet 1210−031−103 Pivot Tab 1210−031−105...

  • Page 37: Siderail Assembly, Right & Left

    Siderail Assembly, Right & Left Assembly part numbers 0721−026−096 (Right) 0721−026−097 (Left) (Left Side Shown) Item Part No. Part Name Qty. 1010−026−015 Top Rail 1010−026−083 Upright 1010−026−084 Upright, Bent 1010−026−082 Spacer 0025−106−000 Semi−Tubular Rivet 1010−026−010 Round Hole Plug 1010−026−085 Upright, Latch 1010−026−012 Bent Spindle Stop...

  • Page 38: Short Transfer System To Frame Assembly

    0721−239−010 Optional Short Transfer System Assembly HEAD END Item Part No. Part Name Qty. (page 38) Transfer System Ass’y, Rt. (page 39) Transfer System Ass’y, Lt. 0010−011−000 Eye Bolt 0038−218−000 Tension Spring 1010−224−025 Spring Retainer 0003−359−000 Hex Hd. Cap Screw 0011−180−000 Flat Washer 0016−118−000...

  • Page 39: Short Transfer System Assembly, Left

    1010−232−010 Short Transfer Board Assembly, Right Item Part No. Part Name Qty. 1010−032−098 Pivot 1010−224−033 Connecting Link Ass’y, Rt. 1010−232−016 Pivot Arm Ass’y, Right 1020−032−100 Transfer Board Ass’y 0011−224−000 Nylon Flat Washer 0014−021−000 Nylon Flat Washer 0016−118−000 Nylock Hex Nut 0028−093−000 Retaining Ring 0003−356−000...

  • Page 40: Short Transfer System Assembly, Right

    1010−232−011 Short Transfer Board Assembly, Left Item Part No. Part Name Qty. 1010−032−098 Pivot 1010−224−033 Connecting Link Ass’y 1010−232−017 Pivot Arm Ass’y, Lt. 1020−032−100 Transfer Board Ass’y 0011−224−000 Nylon Flat Washer 0014−021−000 Nylon Flat Washer 0016−118−000 Nylock Hex Nut 0028−093−000 Retaining Ring 0003−356−000 Hex Hd.

  • Page 41: Long Transfer System To Frame Assembly

    0721−234−010 Optional Long Transfer System Assembly HEAD END Item Part No. Part Name Qty. (page 42) Transfer System Ass’y, Rt. (page 41) Transfer System Ass’y, Lt. 0010−011−000 Eye Bolt 0038−218−000 Tension Spring 0721−224−025 Spring Retainer, Rt. 0003−359−000 Hex Hd. Cap Screw 0011−180−000 Flat Washer 0016−118−000...

  • Page 42: Long Transfer System Assembly, Left

    0721−234−012 Long Transfer Board Assembly, Left Item Part No. Part Name Qty. 0721−024−055 Transfer Board Ass’y 0721−024−046 Label 0721−224−016 Long Pivot, Machined 0721−224−033 Connecting Link Ass’y 0721−232−017 Pivot Arm Ass’y, Lt. 0028−093−000 Retaining Ring 0003−050−000 Hex Hd. Cap Screw 0011−224−000 Nylon Flat Washer 0014−021−000 Nylon Flat Washer...

  • Page 43: Long Transfer System Assembly, Right

    0721−234−013 Long Transfer Board Assembly, Right Item Part No. Part Name Qty. 0721−024−055 Transfer Board Ass’y 0721−024−046 Label 0721−224−016 Long Pivot, Machined 0721−224−033 Connecting Link Ass’y, Rt. 0721−232−016 Pivot Arm Ass’y, Right 0028−093−000 Retaining Ring 0003−050−000 Hex Hd. Cap Screw 0011−224−000 Nylon Flat Washer 0014−021−000...

  • Page 44: Removable I.v. Pole Assembly

    0390−025−000 Standard, Removable I.V. Pole Assembly Item Part No. Part Name Qty. 0024−023−000 Plastic Knob 0390−003−053 Double I.V. Ass’y 0393−003−043 Tube Assembly 0004−496−000 Soc. Hd. Cap Screw...

  • Page 45: Tethered I.v. Pole Mounting Assembly

    0721−117−000 Optional Tethered I.V. Assembly HEAD END Item Part No. Part Name Qty. 0025−133−000 Pop Rivet 0025−179−000 Rivet 0034−022−000 Cable Clamp 1001−159−042 I.V. Plug (page 45) Tethered I.V. Pole Assembly 1211−117−021 Backing Plate 1211−117−022 I.V. Clip...

  • Page 46: Tethered I.v. Pole Assembly

    1211−117−010 Tethered I.V. Pole Assembly Item Part No. Part Name Qty. 0052−017−000 Spacer 1211−117−020 Cable Assembly 0926−400−062 Stop Sleeve 1010−059−016 I.V. Hook 1211−117−011 Extension Rod 1211−117−012 Base Tube Weldment 0004−495−000 Low Hd. Soc. Hd. Cap Screw 1211−117−016 Knob 0014−020−000 Nylon Washer 0004−232−000 Button Hd.

  • Page 47: 2−Stage I.v. Pole Assembly, Foot & Head

    721−400−001 Optional 2−Stage I.V. Assembly Assembly part number 0721−280−000 & 0721−281−000 (reference only) HEAD END FOOT END Item Part No. Part Name (page 47) I.V. Pole Assembly 1001−259−103 I.V. Pivot 0016−118−000 Fiberlock Nut 0004−452−000 But. Hd. Cap Screw 0003−356−000 Hex Hd. Cap Screw 0016−116−000 Flexlock Nut 1001−059−040...

  • Page 48: 2−Stage I.v. Pole Assembly

    1211−210−010 Optional 2−Stage I.V. Pole Assembly Item Part No. Part Name Qty. 0008−031−000 Soc. Hd. Cap Screw 0052−017−000 Washer 0926−400−162 Spacer 1211−210−029 2nd Stage Assembly 1001−359−013 Dampener 1001−159−028 Base Tube 1010−259−016 I.V. Hook (page 48) I.V. Pole Latch 1001−359−112 Pivot...

  • Page 49: Pole Latch Assembly

    1211−210−026 I.V. Pole Latch Assembly Item Part No. Part Name Qty. 0028−167−000 Retaining Ring 0031−004−000 Steel Ball 0038−392−000 Crest−to−Crest Spring 1211−091−034 Release Label 1211−110−018 I.V. Latch Seal 1211−110−020 Washer 1211−110−021 I.V. Latch Locking Pin 1211−110−022 I.V. Latch Guide 1211−110−024 I.V. Latch O.D. Housing 1211−110−035 Washer 1211−110−036...

  • Page 50: 3−Stage I.v. Pole Assembly, Head & Foot

    0721−061−000 Optional 3−Stage I.V. Assembly, Head 0721−062−000 Optional 3−Stage I.V. Assembly, Foot FOOT END HEAD END Item Part No. Part Name Qty. (page 50) I.V. Pole Assembly 1001−259−013 I.V. Pivot 0016−118−000 Fiberlock Nut 0004−452−000 But. Hd. Cap Screw 0003−356−000 Hex Hd. Cap Screw 0016−116−000 Flexlock Nut 1001−059−040...

  • Page 51: 3−Stage I.v. Pole Assembly

    1211−211−010 Optional 3−Stage I.V. Pole Assembly Item Part No. Part Name Qty. 0007−004−000 Truss Hd. Machine Screw 0026−076−000 Roll Pin 0052−017−000 Spacer 1211−210−031 2nd Stage Assembly 0926−400−162 Spacer (page 51) 3rd Stage Assembly 1001−161−023 Base Tube 1010−259−016 I.V. Hook 1010−061−014 Collar (page 48) I.V.

  • Page 52: 3Rd Stage Assembly

    3−Stage I.V. Pole 3rd Stage Assembly Assembly part number 1211−110−032 (reference only) NOTE Item F, part number 1010−061−018 is left hand thread. When removing it, turn clockwise to loosen it. Item Part No. Part Name Qty. 0031−021−000 Ball 0038−303−000 Compression Spring 1010−061−013 Ball Retainer 1010−061−016...

  • Page 53: C−Spine Cassette Holder Assembly

    1001−070−000 C−Spine Cassette Holder Assembly Item Part No. Part Name Qty. 1010−070−025 I.V. Adaptor 1010−070−018 Specification Label 0011−447−000 Flat Washer 0004−054−000 But. Hd. Cap Screw (page 53) Support Pole Assembly (page 54) Storage Bracket Ass’y 0016−118−000 Nylock Nut 0003−356−000 Hex Hd. Cap Screw 1001−070−011 Attachment Bracket 0003−355−000...

  • Page 54: C−Spine Support Pole Assembly

    1010−070−010 C−Spine Support Pole Assembly View A−A Item Part No. Part Name Qty. 1010−070−033 Support Tube Cap 0026−006−000 Roll Pin 1010−070−034 Support Arm Weldment 1010−070−042 Cassette Holder Weldment 1010−070−050 Adjustment Tube Weldment 1010−070−030 Base Tube Weldment 1010−070−045 Knob 0025−055−000 Pop Rivet 1010−070−044 Pivot Pin 0026−005−000...

  • Page 55: C−Spine Storage Bracket Assembly

    1010−070−019 C−Spine Storage Bracket Assembly 6.5” (Ref.) 2” (Ref.) Item Part No. Part Name Qty. 1010−070−020 Storage Bracket Weldment 1010−070−045 Knob 1010−070−023 Storage Label...

  • Page 56: Defibrillator Tray Assembly

    0926−039−000 Optional Defibrillator Tray Assembly Assembly part number 0926−039−010 (reference only) Umbrella Nut/Crosstube Detail Strap Securing Detail Item Part No. Part Name Qty. Item Part No. Part Name Qty. 0946−039−004 Tray 0946−039−003 Support Tube 0926−039−016 Crosstube 0926−001−082 Label 0025−055−000 Rivet 1010−050−021 Long Strap 0926−039−009...

  • Page 57: Foot Extension/Defibrillator Tray Assembly

    1010−050−100 Foot Extension/Defibrillator Tray Ass’y Assembly part number 1010−050−210 (reference only) Label Detail Label Detail Item Part No. Part Name Qty. Item Part No. Part Name Qty. 0008−049−000 Soc. Hd. Shoulder Bolt 1010−050−050 Knob 0014−020−000 Nylon Washer 1010−050−057 “Max. Weight” Label 0014−021−000 Nylon Washer 1010−050−205 Cushion Assembly...

  • Page 58: Foot Board/Chartholder Assembly

    0926−040−100 Foot Board/Chartholder Assembly Assembly part number 0926−040−010 (reference only) Item Part No. Part Name Qty. 0946−028−011 Chart Holder 0946−029−006 Foot Board 1020−030−000 Upright Oxygen Bottle Holder Ass’y Item Part No. Part Name Qty. 1020−030−011 Upright Bottle Holder 0027−012−000 Cotter Pin 1020−030−017 Specification Label...

  • Page 59: O2 Bottle Retainer Assembly

    1040−010−090 Optional O@ Bottle Retainer Assembly Base Hood Item Part No. Part Name Qty. 1040−010−091 Bottle Retainer 1040−010−092 Scrulok Fastener...

  • Page 60: Mattresses And Siderail Pads

    Mattresses and Siderail Pads Mattress, 3” Thick x 24” Wide, Enhanced Comfort ....part # 0721−248−106 Mattress, 4” Thick x 24” Wide, Enhanced Comfort .

  • Page 61: Warranty

    No employee or representative of Stryker is authorized to change this warranty in any way. Stryker Medical stretchers are designed for a 10 year expected life under normal use conditions and appropri- ate periodic maintenance as described in the maintenance manual for each device.

  • Page 62: Return Authorization

    Claims for any short shipment must be made within thirty (30) days of invoice. International Warranty Clause: This warranty reflects U.S. domestic policy. Warranty outside the U.S. may vary by country. Please contact your local Stryker Medical representative for additional information.
  • Page 63 European Representative Stryker EMEA RA/QA Director Stryker France ZAC Satolas Green Pusignan Av. De Satolas Green 69881 MEYZIEU Cedex France 6300 S. Sprinkle Road, Kalamazoo, MI 49001−9799 (800) 327−0770 www.strykermedical.com DH 9/03 0720−009−002 REV A...
