Both the 10/100 Ethernet Socket (E) and the USB 3.0 Socket (F) can be connected to a
network/PC simultaneously. The active interface will be determined by whichever interface
winIDEA connects to first.
When powering on the system, switch the BlueBox unit on before powering on the
Target. When powering down the system, power off the Target before powering off the
BlueBox unit!
FBridge port is not Ethernet port!
Use only original iSYSTEM accessories for powering and connecting with the BlueBox
unit. Consult with iSYSTEM before attempting to use any other accessory.
iC5700 with IOM6 Hub (optional):
I – Three additional FNet ports
J – System port
K – FBridge port (not Ethernet port!) provides synchronization between two iC5700 units.
