15 Settings

15.3 Settings 3

Manufacturer
Nidek
Topcon
56 / 92
On the "Settings 3" screen, you set the communication parameters for the
respective phoropter:
Fig. 15-4: Settings 3
Examples of communication parameters of phoropters that are supported
by Myopia Master® (Status: December 2019):
Phoropter Baud rate
RT-5100
RT-2100 9600
RT-1200S
CV-5000 9600/2400
Fig. 15-5: Parameters for phoropters supported by Myopia Master®
In the "Device-ID" field, you identify the Myopia Master® that is
connected to a phoropter. Assign a Device-ID, e.g. when multiple devices
are connected to a phoropter.
Instruction Manual Myopia Master® (G/68100/EN Rev04 0820)
Parity Stop bits
uneven 1
none 2
Phrpt.protocol
N2
TN
