Interface
Keyboard / touch screen / Kbd Layout / Kbd Mode
Touch beep
Exam.Nr.
Instruction Manual Myopia Master® (G/68100/EN Rev04 0820)
You can deactivate the interfaces.
With the GDT interface, you can link the Myopia Master® to an existing
office software and can thus import and export data.
If you want to connect a phoropter that is supported by PARK
page
56), then activate the option "Phoropter".
If the Myopia Master® is connected to a computer via USB, you need to
set the interface settings to "USB".
In the "Keyboard" field, select the keyboard interface of the touch
screen for input of patient data, for example.
You activate or deactivate the touch screen function in the "Use
Touch" checkbox
In the "Kbd Layout" field, you select the keyboard layout.
QWERTZ stands for the German keyboard layout.
QWERTY stands for the American keyboard layout.
In the field "Kbd Mode", you select the contact control of the touch
screen.
In "Key Down" mode, the characters are input as soon as you make
contact with the touch screen
In "Key Up" ,mode, the characters are input when you stop pressing
the touch screen.
This is the case in "Key Up+" mode too. However, the entered
character is also displayed on the screen:
Fig. 15-3: Kbd Mode "Key Up+", Example: The letter N
If the Checkbox is activated, then a "peep tone" will sound- when the
touch screen is operated.
The "Exam Nr." that appears on every printout for identifications purposes
can be reset to zero at any time.
15 Settings
(fig. 15-5,
55 / 92
