First Time Installation
•
Please read instructions carefully before installation.
•
Check the contents of kit. Contact your Prorack dealer if any parts appear to be missing or damaged.
•
Clean your roof racks and cargo basket prior to fi tting the Recovery Tracks Carrier.
Important Warning
•
It is critical that all Prorack racks and accessories be properly and securely attached to your vehicle. Improper
attachment could result in an automobile accident, and could cause serious bodily injury or death to you or to others.
•
You are responsible for securing the racks and accessories to your car, checking the attachments prior to use, and
periodically inspecting the products for adjustment, wear, and damage.
•
If you do not understand all of the instructions and cautions, or if you have no mechanical experience and are not
thoroughly familiar with the installation procedures, you should have the product installed by a professional installer
such as a roof rack specialist.
Tools Required (for mounting bracket, square bar and cargo basket installations only)
•
13 mm Spanner / 13 mm Socket Wrench
(for Square Bar and Cargo Basket installation only)
•
Tape Measure
Note - this product is optimised to work with the following recovery tracks:
•
Maxtrax MkII
•
Tred 1100 mm & 800 mm
Contents
Installation of Recovery Tracks Carrier plus Mounting Brackets on Prorack HD, Tradesman and other Heavy Duty Crossbars
Go to Page 3
Installation of Recovery Tracks Carrier plus Mounting Brackets on Prorack S-Wing and International T-Slot Crossbars
Go to Page 5
Installing Recovery Tracks Carrier direct to Prorack HD, Tradesman and other Heavy Duty Crossbars
Go to Page 7
Installing Recovery Tracks Carrier direct to Prorack S-Wing and International T-Slot Crossbars
Go to Page 9
Installing Recovery Tracks Carrier direct to P-bar and other square Crossbars
Go to Page 10
Installing Recovery Tracks Carrier on to a Cargo Basket
Go to Page 12
09-13-568-Rev5
Recovery Tracks Carrier
•
Torque Wrench (optional)
•
Padlock (optional)
PR3207
Page 1 of 14

Advertisement

loading
Need help?

Need help?

Do you have a question about the PR3207 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Prorack PR3207

Summary of Contents for Prorack PR3207

  • Page 1 Please read instructions carefully before installation. • Check the contents of kit. Contact your Prorack dealer if any parts appear to be missing or damaged. • Clean your roof racks and cargo basket prior to fi tting the Recovery Tracks Carrier.
  • Page 2 Page 2 of 14 09-13-568-Rev5...

  • Page 3: Mounting Bracket

    Installation of Recovery Tracks Carrier plus Mounting Brackets on Prorack HD, Tradesman and other Heavy Duty Crossbars Check crossbar spread is between 492 mm to 892 mm. Insert 2 x M8 Spring Nuts at an equal distance from the ends of each crossbar. Push Spring Nuts down into the crossbar channels and twist to lock into place as pictured.
  • Page 4 Check the mounting position of the Baseplates by placing them on to the Mounting Brackets. The middle Baseplate channels must align with the M8 slot Nuts in the Mounting Brackets. Note the narrow ends of the Baseplates face towards the front and rear of the vehicle. Set the distance between the inside of the Baseplates according to your Recovery Track type: TRED 800 = 235 mm TRED 1100 / MAXTRAX MKII = 440 mm...
  • Page 5 Baseplates. Tighten Straps fi rmly and secure the Velcro sections. Installation of Recovery Tracks Carrier plus Mounting Brackets on Prorack S-Wing and International T-Slot Crossbars Check crossbar spread is between 492 mm to Referring to Figure 3, secure the 2 x Mounting 892 mm.
  • Page 6 Check the mounting position of the Baseplates by placing them on to the Mounting Brackets. The middle Baseplate channels must align with the M8 slot Nuts in the Mounting Bracket. Note the narrow ends of the Baseplates face towards the front and rear of the vehicle. Set the distance between the inside of the Baseplates according to your Recovery Track type: TRED 800 = 235 mm TRED 1100 / MAXTRAX MKII = 440 mm...
  • Page 7 Baseplates. Tighten Straps fi rmly and secure the Velcro sections. Installation directly onto Prorack HD, Tradesman And Other Heavy Duty Crossbars Check crossbar spread is between 492 mm to 892 mm. Position Baseplates onto separate crossbars noting the narrow ends face towards the front and rear of the vehicle.
  • Page 8 Referring to Figure 5, loosely fi t 2x Fig. 5 Baseplates to the M8 Spring Nuts in the M8 Socket Head Crossbars. Capscrew 25 mm M8 Spring Washer M8 Washer Recheck the measurements between the insides of the Baseplates from step 1 and ensure center Baseplate channels align.
  • Page 9 Installation directly onto Prorack S-Wing and International T-Slot Crossbars Check crossbar spread is between 492 mm to 892 mm. Position Baseplates on to separate crossbars noting the narrow ends face towards the front and rear of the vehicle. Set the distance between the inside of the Baseplates according to your Recovery Track type:...
  • Page 10 Attach Straps by hooking the metal webbing buckles from behind through the side holes on the Baseplates. Ensure that the buckles are sitting fl ush against the Baseplate as pictured, that the Velcro section of the Adjuster Strap is facing forward and that the Velcro section of the Fixed Strap is facing backward.
  • Page 11 Position 2 x Clamp Plates underneath the Crossbar for each Baseplate. Ensure the Clamp Plate holes align with the outer Baseplate channel on either side of the Crossbar. Note - Your crossbar spacing and track size will determine where in the outer Baseplate channels to secure to the crossbars to obtain the recommended distance.
  • Page 12 Installation onto Cargo Basket Place the Baseplates in to the basket. TRED 800 235 mm 55 mm 45 mm Set the distance between the inside of the Baseplates according to your Recovery Track type: TRED 1100 TRED 800 = 235 mm 440 mm 70 mm 140 mm...

  • Page 13: Optional Installation Procedures

    Recovery Tracks. Secure with padlock (not provided). Note - Fitment to Mounting Brackets on Prorack HD shown Additional Nuts are included so that accessories such as the Prorack Shovel Holder (PR3204) can be mounted onto the back of the Accessory Brackets.
  • Page 14 Never drive into a car wash with the roof rack system or accessories fi tted. • Do not exceed the vehicle manufacturer’s roof load rating. Total load equals weight of roof racks + accessories + cargo/ equipment. Prorack Freephone www.prorack.co.za 17 Hinkler Court, Brendale AU: 1800 143 548 www.prorack.com.au...
