Small Engine Management Evaluation Board
User Manual for TLE8082ES+TLE8080EM Evaluation Board
The jumper options are descriped in the table below.
Table 8 Jumper Options
Jumper
KEY on signal
Watchdog disable
Supply to external
Reset options
Arduino signals
1.1.4

LEDs

The Evaluation board provides LEDs to indicate the voltage levels of TLE8082ES. The meaning of the status
LEDs is descriped below.
Table 9 LED description
LED designation
V5DD
VIO
COM5V
1.2

Schematic and Layout

This chapter provides the schematics and layout of the Evaluation board at a glance.
User Manual
Jumper Designation
J1
J2
R21 (default open)
R24 (default open)
R27 (default open)
R17, R9, R10, R19, R20, R18, R30 Open/close for use of Arduino specific signal
TLE8082ES Pin designation
V5DD
VIO
COM5V
Description
Close to wake up TLE8082ES
Close to disable watchdog function of
TLE8080EM
Close to provide 5V to external via J502-5
Close to provide 5V to external via J502-2
(VIO signal)
Connect TLE8082ES NRIO and TLE8080EM
NRO to control TLE8082ES reset with
TLE8080EM
for other purposes
Description
Glows if 5V of V5DD is active
Glows if VIO voltage is active
Glows if COM5V voltage is active
10 V1.0
2021-04-28
