8.2.1 Parameters, Class 100 and Class 101 Objects (Read/Write)

Table 9: Objects with Class, Instance, and Attribute
Object name
Class 100 objects
Motor details
Command Source
Motor Full Load Current
Motor kW
Locked Rotor Time
Locked Rotor Current
Motor Service Factor
Reserved
Motor start/stop
Start Mode
Start Ramp Time
Initial Current
Current Limit
Adaptive Start Profile
Kickstart Time
Kickstart Level
Jog Torque
Stop Mode
Stop Time
Adaptive Stop Profile
Adaptive Control Gain
Multi Pump
Start Delay
DC Brake Torque
DC Brake Time
Brake Current Limit
Soft Brake Delay
Motor start/stop 2
Motor Full Load Current-2
26 | Danfoss A/S © 2020.12
Class Instance Attribute
100 101 100
100 102 100
100 103 100
100 104 100
100 105 100
100 106 100
100 107 100
100 108 100
100 109 100
100 110 100
100 111 100
100 112 100
100 113 100
100 114 100
100 115 100
100 116 100
100 117 100
100 118 100
100 119 100
100 120 100
100 121 100
100 122 100
100 123 100
100 124 100
100 125 100
100 126 100
Object name
Motor kW-2
Start Mode-2
Start Ramp Time-2
Initial Current-2
Current Limit-2
Adaptive Start Profile-2
Kickstart Time-2
Kickstart Level-2
Jog Torque-2
Stop Mode-2
Stop Time-2
Adaptive Stop Profile-2
Adaptive Control Gain-2
Multi Pump-2
Start Delay-2
DC Brake Torque-2
DC Brake Time-2
Brake Current Limit-2
Soft Brake Delay-2
Auto-start/stop
Auto-Start/Stop Mode
Run Time
Stopped Time
Sunday Mode
Sunday Start Time
Sunday Stop Time
Monday Mode
Monday Start Time
Monday Stop Time
Tuesday Mode
AN353423548483en-000101 / 130R0945
Attributes
Class Instance Attribute
100 127 100
100 128 100
100 129 100
100 130 100
100 131 100
100 132 100
100 133 100
100 134 100
100 135 100
100 136 100
100 137 100
100 138 100
100 139 100
100 140 100
100 141 100
100 142 100
100 143 100
100 144 100
100 145 100
100 146 100
100 147 100
100 148 100
100 149 100
100 150 100
100 151 100
100 152 100
100 153 100
100 154 100
100 155 100
