Modbus Registers
7.4.2 Command and Configuration
Registers (Read/Write)
Register Description Bits Details
40001 Command (single 0–7
write)
8–14 Reserved
15
40002 Reserved
40003 Reserved
40004 Reserved
40005 Reserved
40006 Reserved
40007 Reserved
40008 Reserved
2) Parameter 0–15 Manage soft starter
40009 –
management
40200
(single/multiple
read or multiple
write)
Table 7.1 Command and Configuration Registers
1) Ensure that the programmable input is not set to Motor Set Select
before using this function.
2) See the relevant soft starter manuals for a complete parameter list.
The first product parameter is always allocated to register 40009. The
last product parameter is allocated to register 40XXX, where XXX =
008 plus total number of available parameters in the product. The
Modbus TCP Module can read or write a maximum of 125 registers in
1 operation. These registers support multiple write (Modbus function
code 16). Attempting to write a single register returns a fault code 01
(illegal function code).

MG17N102

Installation Guide
To send a command to the
soft starter, write the
required value:
00000000 = Stop
00000001 = Start
00000010 = Reset
00000100 = Quick stop
(coast to stop)
00001000 = Forces
communication trip
00010000 = Start using
1)
Parameter Set 1
00100000 = Start using
1)
Parameter Set 2
01000000 = Reserved
10000000 = Reserved
Must = 1
programmable parameters
Danfoss A/S © 10/2017 All rights reserved.
7.4.3 Status Reporting Registers (Read
Only)
NOTICE
For models MCD5-0053B and smaller (soft starter model
ID 1–4), the current reported via communication
registers is 10 times greater than the actual value.
NOTICE
The following functions are only available with MCD 500
soft starters:
•
Parameter management
•
Dual motor control
•
Digital inputs
•
Jog
•
Current measurement in amperes
•
Power information
•
Warnings
MCD 201 open-loop soft starters do not support motor
current and motor temperature information.
Register Description Bits
30240 Soft starter state 0–3
4
5
6
7–15
30241 Trip code 0–7
8–15
30242 Motor current 0–7
8–15
30243 Motor 0–7
temperature
8–15
30244– Reserved
30249
Details
1 = Ready
2 = Starting
3 = Running
4 = Stopping (including
braking)
5 = Restart delay (including
temperature check)
6 = Tripped
7 = Programming mode
8 = Jog forward
9 = Jog reverse
1 = Positive phase sequence
(only valid if bit 6 = 1)
1 = Current exceeds FLC
0 = Uninitialized
1 = Initialized
Reserved
See chapter 7.6 Trip Codes
Reserved
Average 3-phase motor
current [A]
Reserved
Motor thermal model (%)
Reserved
