Packet Structures
Object name
Brake torque-2
Brake time-2
Language
User screen - top left
User screen - top right
User screen - bottom left
User screen - bottom right
Graph timebase
Graph maximum adjustment
Graph minimum adjustment
Mains reference voltage
Access code
Adjustment lock
Emergency run
Current calibration
Main contactor time
7 7
Bypass contactor time
Motor connection
Jog torque
Motor overload
Current imbalance
Undercurrent
Instantaneous overcurrent
Frequency
Heat sink overtemperature
Table 7.9 Class 100 Objects

7.3.2.2 Class 101 Objects (Read/Write)

Object name
Excess start time
Input A trip
Motor thermistor
Starter communication
Network communication
Battery/clock
Low control volts
Comms timeout
Tracking gain
Tracking gain-2
Frequency detect
Bypass protection
Pedestal detect
Table 7.10 Class 101 Objects
18
EtherNet/IP Module
Class Instance Attribute
100 175 100
100 176 100
100 177 100
100 178 100
100 179 100
100 180 100
100 181 100
100 182 100
100 183 100
100 184 100
100 185 100
100 186 100
100 187 100
100 188 100
100 189 100
100 190 100
100 191 100
100 192 100
100 193 100
100 194 100
100 195 100
100 196 100
100 197 100
100 198 100
100 199 100
Class Instance Attribute
101 100 100
101 101 100
101 102 100
101 103 100
101 104 100
101 105 100
101 106 100
101 107 100
101 108 100
101 109 100
101 110 100
101 111 100
101 112 100
Danfoss A/S © 05/2017 All rights reserved.

7.3.2.3 Class 103 Objects (Read-only)

Object name
Binary protocol version
Product type code
Minor software version
Major software version
Soft starter model
Parameter changed
Num parameter
Parameter value
Access type
Starter state
Warning
Initialized
Reserved
Parameters have changed
Phase sequence
Trip/warning code
Current
Current % of FLC
Motor 1 temperature
Motor 2 temperature
Power (W)
Power scale
% power factor
Voltage (refers to mains reference
voltage)
Phase 1 current
Phase 2 current
Phase 3 current
Phase 1 voltage (refers to mains
reference voltage)
Phase 2 voltage (refers to mains
reference voltage)
Phase 3 voltage (refers to mains
reference voltage)
Minor revision
Major revision
Table 7.11 Class 103 Objects
Class Instance Attribute
103 100 100
103 101 100
103 102 100
103 103 100
103 104 100
103 105 100
103 106 100
103 107 100
103 108 100
103 109 100
103 110 100
103 111 100
103 112 100
103 113 100
103 114 100
103 115 100
103 116 100
103 117 100
103 118 100
103 119 100
103 120 100
103 121 100
103 122 100
103 123 100
103 124 100
103 125 100
103 126 100
103 127 100
103 128 100
103 129 100
103 130 100
103 131 100
