8.3.2 Vendor-specific Objects

The EtherNet/IP module supports vendor-specific classes 100, 101, 102, 103, and 104.

8.3.2.1 Class 100 ~ 102 Objects (Read/Write)

Class 100 ~ 102 objects allow parameter values to be read from and written to the soft starter.
• Class 100d (0x64): Parameters 1–99
• Class 101d (0x65): Parameters 100–199
• Class 102d (0x66): Parameters 200~299
Parameter lists vary according to the model and version of the soft starter. See the relevant soft starter operating guide for a
complete parameter list.
When writing parameter values, the EtherNet/IP module will update all parameter values in the soft starter. Always enter a valid
value for every parameter.
Changing the values of the Factory parameters (parameter group 20-**) may cause unpredictable behavior in the soft starter. Con-
sult a local supplier before adjusting the Factory parameters.

8.3.2.2 Class 103 Objects (Read Only)

Class 103d (0x67) allows soft starter state information to be read from the soft starter.
Table 6: Objects to be Read from the Soft Starter
Object name
Binary protocol version
Product type code
Reserved
Reserved
Soft starter model
Changed parameter number
Number of parameters
Changed parameter value
Reserved
Soft starter state
1 = Ready
2 = Starting
3 = Running
4 = Stopping (including braking)
5 = Restart delay (including temperature check)
6 = Tripped
7 = Programming mode
8 = Jog forward
26 | Danfoss A/S © 2022.10
N O T I C E
N O T I C E
N O T I C E
Packet Structures
Class Instance Attribute
103 100 100
103 101 100
103 102 100
103 103 100
103 104 100
103 105 100
103 106 100
103 107 100
103 108 100
103 109 100
