10- Engine installation / Motoreinbau
11- Fuel tank installation / Tankeinbau
To muffler
Filler tube
X
To engine
5/32"(4mm)
After confirming the direction . Insert
and tighten the screw.
12- Servo installation / Servoeinbau
NOTE: Place of the throttle servos
may be change depend of engine.
(Four-stoke or two-stroke engine)
TOP VIEW
Cowling mount
Cowling mount
Throttle servo
Drosselservo
Servo mount
Servohalterung
Draufsicht
118 ~ 122mm
Engine thrust on balk head
is already adjust at factory
Elevator servo
Hohenruderservo
Push the fuel tank forward until
there are no gaps between the
tank and firewall.
