KING QUEST 100
WARNING! This radio controlled model is NOT a toy. If modified or flown carelessly it could go out of controll and
cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough.
Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.
Radio control model
ALL BALSA, PLYWOOD CONSTRUCTION AND ALMOST READY TO FLY
Instruction manual
SPECIFICATIONS
Wingspan:.....................................2210mm
Length:..........................................1580mm
Electric Motor:.........................2300-2500w
Glow Engine:..............90-120 2-T / 120 4-T
RTF Weight: 5.8-6.1kg (Will vary with
Equipment Used).
Radio:.......Minimum 7 Channels / 9 Servos
Function: Ailerons-Elevator-Rudder-Throttle
Flaps.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KING QUEST 100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VQ Models KING QUEST 100

Summary of Contents for VQ Models KING QUEST 100

  • Page 1 Radio control model KING QUEST 100 ALL BALSA, PLYWOOD CONSTRUCTION AND ALMOST READY TO FLY Instruction manual SPECIFICATIONS Wingspan:........2210mm Length:..........1580mm Electric Motor:......2300-2500w Glow Engine:....90-120 2-T / 120 4-T RTF Weight: 5.8-6.1kg (Will vary with Equipment Used). Radio:..Minimum 7 Channels / 9 Servos Function: Ailerons-Elevator-Rudder-Throttle Flaps.
  • Page 2 REQUIRED FOR OPERATION (Purchase separately) Servo extension cord 700mm for Aileron servos (2pcs) 400mm for Flap servos (2pcs) 600mm for Elevator and Rudder servos (3pcs) 26cc Gas Engine 120-4T Glow Engine 2300-2500 Watt Minimum 7 channels radio for airplane with 9 servos 6 standard servo for Aileron.
  • Page 3 KING QUEST 100 1-Nose gear mount 1- Slide one end of the 2x500mm white plastic tube into the pre-drilled hole on the right side of the nose gear mount, the end of the plastic tube fits across the front of the fire-wall. The other end of the plastic tube leads to where the nose gear servo arm will be.

  • Page 4: Installing The Engine Mount

    QUEST KODIAK 3-Installing the nose gear & nose gear arm 4-Installing the engine mount Hex wrench Drill expands to 6mm Attach the engine mount to the fire-wall using four of the 4x25mm hexagonal bolt, washer and blind nut. 4x25mm hexagonal bolt ..4 Washer and blind nut ..4...

  • Page 5: Installing The Engine

    QUEST KODIAK 5-Installing the engine Position the engine to the engine mounts so the distance from the prop hub to the fire-wall is 139mm. Mark the engine mounting plate where the four holes are to be drilled. 139mm Remove the engine and drill a 4mm holes through the beam at each of the four marks made above.
  • Page 6 QUEST KODIAK 6-Installing the engine Reposition the engine on the engine mount beams, aligning it with the holes. Secure the engine to the engine mount using four 4x25mm hexagonal bolt. Note: Apply Silicon sealer to each of the 4x25mm hexagonal bolt and nut. 4x25mm screw ..4 4mm Washer...
  • Page 7 QUEST KODIAK 8-Installing the electric motor mounting 6x100mm bolt..4 6mm nut..12 6mm washer...16 Attach the four of the 6x100mm bolts washer and nuts to the fire-wall as shown. Secure the Motor to the wooden motor mounting plate using the four of the 3x20mm hexagonal bolts, washer and nut. 3x20mm screw ..4 3mm Washer...

  • Page 8: Installing The Main Landing Gear

    QUEST KODIAK 9-Installing the main landing gear Remove the adhesive tape and remove the cover from the fuselage. 4x15mm hexagonal bolt ..6 Step 1 Step 2 A=42mm 3x20mm bolt Step 3 Step 4 5 min.
  • Page 9 QUEST KODIAK 10-Installing the main landing gear 3x12mm self-drilling screw ...2 Put the cover back on the fuselage and secure it with two 3x12mm self-drilling screws.
  • Page 10 QUEST KODIAK 11-Installing the main landing gear Narrow end Mark to drill Mark to drill Plastic landing gear cover, view from the narrow end. Step 1 When putting the plastic gear cover on the aluminum landing gear, you have to separate the two pieces of plastic gear cover a litter on the narrow end (Step 1), once it is in place, you will glue the separated part with thin CA glue (Step 2).
  • Page 11 QUEST KODIAK 12-Installing the main landing gear 2x8mm self-drilling screw ...12 2x8mm self-drilling screw ...12 75mm wheel ...2 4X45mm screw ...2 4mm nut ....4 4mm washer ....6 4mm nut 4mm nut 4x45mm screw Aluminum landing gear...

  • Page 12: Installing The Horizontal Stabilizer

    QUEST KODIAK 13-Installing the horizontal stabilizer Step 1 Pull the left and right elevator out of the horizontal stabilizer (not glue yet). Step 2 Step 3 Cut away only the covering. sander Using a sharp hobby knife, carefully cut away the covering around of all slots for the horizontal stabilizer and vertical fin installation.
  • Page 13 QUEST KODIAK 14-Installing the horizontal stabilizer Step 6 Aluminum wing joiner Aluminum wing joiner Horizontal stabilizer Horizontal stabilizer When viewing visually from the back of the fuselage, the aluminum wing joiner should be parallel to the horizontal stabilizer. When you are satisfied with the alignment, use a pencil to trace around the top and bottom of the stabilizer where it meets the fuselage.
  • Page 14 QUEST KODIAK 15-Installing the horizontal stabilizer Control horn 5 min. Epoxy ..2 set 2x20mm bolt ..4 5 min. Epoxy 16-Installing the verticaltal stabilizer Trial fit the vertical stabilizer in position. Ensure that the vertical stabilizer is perpendicular to the horizon stabilizer. Cut away only the covering.

  • Page 15: Installing The Vertical Stabilizer

    QUEST KODIAK 17-Installing the vertical stabilizer Cut away only the covering inside the pencil line. Glue the torque rod bearing into the slot in the vertical stabilizer, using a thin layer of 5 minute epoxy. 5 min. Epoxy 15 min. Epoxy...
  • Page 16 QUEST KODIAK 18-Installing the vertical stabilizer Use a pencil to mark the leading edge of the rudder where the rudder torque rod meets. Drill a hole 2.5mm in diameter on the leading edge marked with a pencil, making sure that you drill the 2.5mm hole perpendicular to the leading edge of the rudder.
  • Page 17 QUEST KODIAK 19- Flap & Aileron servo FLAP & AILERON SERVO HATCH - BOTTOM VIEW Hard wood servo mount IMPORTANT: To be safe, you must attach the four screws as shown in this picture. 2x8mm Thin CA 1.5mm ! Securely glue together. If coming off during fly, 2x8mm you lose control of your air plane.
  • Page 18 QUEST KODIAK 20- Flap & Aileron linkages Control horn ...1 set Control horn ....1 Thin CA AILERON LINKAGE 3x175mmm push-rod 3mm connector FLAP LINKAGE 2x175mmm push-rod 2x175mm rod with clevis one end ..1 set 2mm connector 3x175mm rod with clevis one end ..1 set...
  • Page 19 QUEST KODIAK 21- Flap & Aileron linkages 3x15mm self drilling screw ....1 Do the same way with other wing half. Aluminum wing brace. The hole on the wing surface is already pre-drilled. Aluminum wing brace. Light Step 1 Step 2 1.2x8mm self-drilling screw .....6 22- Dowel installation...
  • Page 20 QUEST KODIAK 23- Elevator & Rudder servo Control horn ...2 set 2mm connector ..1 2mm connector 3mm connector ..2 3mm connector 24- Elevator & Rudder linkages 3x175mm elevator push rod Rudder torque rod 3x175mm elevator push rod 2x175mm rudder push rod 2x175mm rod with clevis one end ..1 set 3x175mm rod with clevis one end...

  • Page 21: Plastic Shield

    QUEST KODIAK 25- Plastic shield 1.5mm Do the same way with other side. 2x8mm self-drilling screw ...8 26- Throttle & Nose gear serov 1.2x500mm nose gear push rod ....1 2x500mm throttle rod with clevis one end ....1 2mm connector ......2 Li-po battery or Fuel tank area...
  • Page 22 QUEST KODIAK 27- Cowling Adhesive tape Transparence plastic Use a marker pen to draw the places that need to be cut so that the engine, silencer, nose gear do not touch the cowling. Remove the engine from the engine mount. Attach the cowling to the fuselage so that the length from the fire-wall to the front of the cowling is 140mm.
  • Page 23 QUEST KODIAK 28- Cowling Cut off the area inside the draw line.
  • Page 24 QUEST KODIAK 29- Cowling Nose gear arm Nose gear push-rod Step 1 Step 3 Step 2...
  • Page 25 QUEST KODIAK 30- Nose gear 2x8mm self-drilling screw .....9...

  • Page 26: Nose Wheel

    QUEST KODIAK 31- Nose wheel 4x40mm screw ...1 4mm washer ...2 4mm nut ...3...
  • Page 27 QUEST KODIAK 32- Nose wheel (in case of Electric motor using)
  • Page 28 QUEST KODIAK 33- Nose wheel (in case of Electric motor using) 2x8mm self-drilling screw .....12...
  • Page 29 QUEST KODIAK 34- Pilot’s seat and canopy Magnet Rectangular slots on the floor. Remove the pilot’s seat: gently push the seat Put the pilot seat in place: Press the 4 ledges under forward and lift it. the base of the pilot’s seat into the 4 slots in the floor of the plane.

  • Page 30: Installing The Wings

    QUEST KODIAK 35- Installing the wings Aluminum wing joiner Aluminum wing brace 3mm blind nut 7x70mm nylon bolt Cut away only the covering ..2 3x15mm hexagonal bolt ....2 3mm blind nut ......2...
  • Page 31 QUEST KODIAK 36- Top hatch Magnetic hatch 37- Sticker IMPORTANT: Please do not clean your model with strong solvent or pure alcohol, only use kerosene to keep the colour of your model not fade. Sticker...
  • Page 32 QUEST KODIAK 38- Balance and control surface THE CENTER OF GRAVITY IS LOCATED 92 - 97mm BACK FROM THE LEADING EDGE OF THE WING, AT THE FUSELAGE. BALANCE A PLANE UPSIDE DOWN WITH THE FUEL TANK EMPTY. DO NOT try to fly an out-of-balance model ! 92-97mm 30mm 12mm...
