Power Rating

Exercise
1. From the ServoStudio navigation sidebar, select Power Rating.
The Power Rating screen is displayed.
2. Check the power rating details for each stepIM in the Demo Kit.
Note:
You should not change any of the values displayed in this screen, even
though some of them can be manipulated.
Exercise
Answer the following questions:
What is the DC voltage that is being applied to the motor?

What is the temperature of the control board?

Refer to the User Manual. What is the temperature value that will result in

an over-temperature error.
Refer to Answers to Exercises at the end of this manual.
