70
Use one of the following methods to zoom in:
1. Click anywhere on the image. The area around the pointer
is magnified and the magnified image is centered where
you clicked. Each click magnifies the image to the next
magnification: 2:1, 4:1, 8:1, 16:1.
2. Click and drag the pointer to draw a box around a specific
area. Release the mouse button. The unit magnifies the
selected area to the nearest magnification: 2:1, 4:1, 8:1, 16:1.
Zoom Out — Use this option to display a wider view of the
magnified portion of the image. The pointer becomes a mag-
nifying glass with a minus sign.
To zoom out, click anywhere on the image. A wider view is
displayed, centered on the point where you clicked. Each click
displays more of the image and reduces the image detail one
level.
Clicking the mouse pointer has no effect once the image is dis-
played at its original size.
NOTE: You can also use this option to zoom in: Click and drag
the pointer to draw a box around a specific area. Re-
lease the mouse button. The unit magnifies the selected
area and displays it in the image area.
Move — Use this option to view a different area of the image
when magnified. The pointer becomes a four-direction arrow.
To move the view:
1. Click and drag the image to the right, left, up, down or
diagonally.
2. Release the mouse button when the desired portion of the
image appears.
Enhance — Use this option to enhance the image when zoom-
ing. As an image is enlarged, it becomes jagged. This feature
reduces jaggedness. The brightness chart (if displayed) also
reflects the changes.
Intellex ® Operating Instructions
