66
NOTE: The mouse pointer changes to
invalid location.
c. Click the mouse button to lock this boundary and start
a new one.
d. Repeat these steps until you are ready to enclose the
target area.
e. Use one of the following methods to enclose the tar-
get area:
• Set at least three endpoints. Then hold the mouse
pointer over the last endpoint and double-click the
button. The boundary lines disappear and the tar-
get area is defined by a semitransparent grid.
• Move the mouse pointer to the starting point and
click the mouse button. The boundary lines dis-
appear and the target area is defined by a semi-
transparent grid.
4. Click Apply to apply the configuration and close the Pe-
rimeter Violation screen.
5. Click Cancel to close the Perimeter Violation screen with-
out saving any changes.
Intellex ® Operating Instructions
if you move it to an
