Chapter 2 — Basic Live Operation
11. 1x1 — Click to select the single window format (1x1). Only
one camera can be displayed at a time unless you start
camera sequencing. See Screen Format and Camera Sequenc-
ing for more information.
12. 2x2 — Click to select the four-window (2x2) format. Up to
four cameras can be displayed at the same time. See Screen
Format for more information.
13. 3x3 — Click to select the nine-window (3x3) format. Up
to nine cameras can be displayed at the same time. See
Screen Format for more information.
14. 4x4 — Click to select the 16-window (4x4) format. Up to
16 cameras can be displayed at the same time. See Screen
Format for more information.
15. Status — Click to display the unit's status screen. See Re-
viewing Unit Status for more information.
16. Seq (Sequence) — Click to display cameras sequentially.
See Camera Sequencing for more information.
17. Full Scrn — Click to hide the controls and indicators and
to display the current images full-screen in the selected
screen format (see Full-Screen Format).
18. Search — Click to search the image database for specific
video images.
19. Utility — Click to access the Utility Options screen (see Util-
ity Options).
20. Archive — Click to access the Archive Options screen (see
Archive Operation).
21. Setup — Click to access the system configuration options
(see Chapter 4 — Intellex Setup Options in the Intellex Instal-
lation Instructions).
22. Help — Click to display online help information.
19
