Chapter 2 — Basic Live Operation

Switch to Menu

Image Area Zoom

3. Select Mode. The unit displays a list of screen modes: 1x1,
2x2, 3x3, 4x4.
4. Select the desired screen format. The unit immediately
changes the image area.

Cancel

Select this option to close the Image Area Popup menu. The
screen remains unchanged.
When you right-click the mouse in full-screen mode, the fol-
lowing screen appears:
The Switch to Menu option appears in place of Switch to Full
Screen.
Select this option to exit full-screen mode and display the images
in the selected screen format with the controls and indicators.
Right-click the mouse and select Switch to Full Screen to hide
the controls and indicators and display the screen format full-
screen again.
At any time, in either menu mode or full-screen mode, you
can zoom to a specific area of the live image screen. Then you
can observe activity from that camera more closely.
1. (2x2, 3x3 or 4x4 format only) Click the desired camera im-
age. The unit displays the selected camera in the 1x1 for-
mat and changes the mouse pointer to
23
.
