Chapter 1 — Introduction

INTELLEX FEATURES

• Enhanced triplex operation provides simultaneous
record/display, playback and archiving.
• IntelleCord filters identify types of activity during record-
ing (see Filter Descriptions for more information). They ig-
nore images with unimportant activity, making efficient
use of recording capacity.
• Use Smart Search filters to quickly search the image data-
base for video segments containing specific types of activ-
ity (see Filter Descriptions for more information). Play back
these video segments.
• Use date and time, camera and alarm criteria to quickly
search the image database. Play back these video segments.
• Records and stores pre-alarm images according to each
camera's pre-alarm setting (0 to 60 seconds).
• Compatible with color and B&W video cameras or other
NTSC/EIA (PAL/CCIR) standard compatible video
sources. Video synchronization is not required.
• Records images digitally, which eliminates the need for
VCRs and video tape. Backs up images to an optional Digi-
tal Audio Tape (DAT), saves them to a floppy diskette or
transfers them to video tape.
• User can select, enhance and copy images onto a computer
diskette or print them.
• Multicamera live displays are available for any camera in
any position in the following formats: 1x1, 2x2, 3x3 and
4x4. A full-screen view hides the controls and fills the en-
tire screen.
• Provides outstanding picture quality using a 640x480 pixel
display (800x600 in full-screen mode) with 256 gray levels
and over 16 million colors.
• Offers seven record rates: NTSC — 60, 45, 30, 15, 7.5, 2.5
and 1 images per second (ips); PAL — 50, 37.5, 25, 12.5,
6.25, 2 and 0.8 ips.
• An optional live monitor (NTSC/EIA or PAL/CCIR) may
be installed. In this configuration, the unit displays live
images on the optional monitor, even when the unit is in
playback mode.
• The mouse pointer provides access to all unit functions.
3
