Chapter 2 — Basic Live Operation

Camera Sequencing

To return to the normal screen:
Right-click the mouse and select Switch to Menu to exit full-
screen mode and display the controls and indicators again (see
Switch to Menu).
The unit can display cameras sequentially in any available for-
mat. Cameras display in camera number order at the Live Dis-
play Sequencer Dwell rate (see Display Setup in the Intellex
Installation Instructions).
In the single-pane format, the unit displays images from each
camera in camera order.
In multi-pane formats, cameras appear in their assigned loca-
tions. Cameras without assigned locations appear sequentially
in the lower right window.
NOTE: Sequencing stops when an alarm occurs. You must
acknowledge the alarm before you can start camera
sequencing again. If you do nothing, sequencing re-
sumes as soon as the unit clears the alarm (see Alarm
Operation ).
To start camera sequencing:
1. Select the screen format: 1x1, 2x2, 3x3 or 4x4.
2. Click the Seq button. The unit switches cameras in the
lower right window (or full-screen) at the Live Display
Sequencer Dwell rate.
To stop camera sequencing:
Use one of the following methods:
• Click the Seq button. Sequencing stops and cameras dis-
play in the previous format.
• Click any format button (1x1, 2x2, 3x3 or 4x4). Cameras
display in the appropriate format.
• Click any camera button (1–16). The selected camera dis-
plays in the single-pane format.
25
