36
Play/Pause knob — Use the Play/Pause knob to change the
playback speed and direction. Images can be played back in
forward or reverse direction, using a speed scale from one to
five.
In Play mode, the unit uses a higher speed scale and plays
images faster. In Pause mode, the unit uses slow motion and
plays images slower.
During playback, when you turn the knob, the unit displays
one of the following on the Play/Pause button:
Forward playback at nX speed (1X to 5X)
Play nX
Play –nX Reverse playback at –nX speed (–1X to –5X)
nX Pause Playback is paused; forward playback in slow
motion, speed indicated by nX (1X to 5X)
–nX Pause Playback is paused; reverse playback in slow
motion, speed indicated by –nX (–1X to –5X)
To play back images in forward direction:
NOTE: The farther you turn the knob clockwise, the quicker
the playback fast forwards.
1. Click the Play/Pause button to select either Play mode or
Pause mode.
2. Turn the Play/Pause knob clockwise. The speed (1X to
5X) is displayed on the Play/Pause knob.
3. To return to normal speed (Play mode) or to pause play-
back (Pause mode), simply release the knob.
To play back images in reverse direction:
NOTE: The farther you turn the knob counterclockwise, the
faster the playback proceeds in reverse.
1. Click the Play/Pause button to select either Play mode or
Pause mode. The unit displays Play or Pause.
2. Turn the Play/Pause knob counterclockwise. The speed
(–1X to –5X) is displayed on the Play/Pause knob.
