A7113F
02/21
Copyright 2014. 2021, Sargent Manufacturing Company, an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Sargent Manufacturing Company is prohibited.
KP
KP Series 10G77
Keypad 10 Line Lock
Installation & Programming
Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sargent KP Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Assa Abloy Sargent KP Series

  • Page 1 Keypad 10 Line Lock Installation & Programming Instructions A7113F 02/21 Copyright 2014. 2021, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
  • Page 2: Table Of Contents

    KP Series Keypad 10 Line Lock Table of Contents Regulatory Compliance ............3 Warning ...................3 General Description ..............4 Specifications ................4 Features ...................4 Parts Breakdown ..............5 Installation Instructions ............8 Programming Instructions ............16 Troubleshooting ..............22 A7113F • 800-810-WIRE (9473) • www.sargentlock.com...
  • Page 3: Regulatory Compliance

    KP Series Keypad 10 Line Lock Regulatory Compliance Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 4: General Description

    KP Series Keypad 10 Line Lock General Description The SARGENT Keypad 10 Line Lock is designed for areas which require standalone authorized entry. It is a self-contained microprocessor-controlled keypad with non-volatile memory. The keypad will hold a total of 99 different User Codes. User Codes “01” and “03” are utilized for Master Code and Supervisory Code, respectively.
  • Page 5: Parts Breakdown

    KP Series Keypad 10 Line Lock Parts Breakdown ITEM PART NUMBER DESCRIPTION REQ’D *10-0523 “B” Inside lever/regular and 30- *10-2204 “J” Inside lever/regular and 30- *10-0503 “L” Inside lever/regular and 30- *10-0547 “P” Inside lever/regular and 30- *10-0536 “B” Inside lever/75 handicap warning *10-2247 “J”...
  • Page 6 KP Series Keypad 10 Line Lock Parts Breakdown (Continued) ITEM PART DESCRIPTION NUMBER REQ’D 10-2642 77 Lockbody (std, 10, 21, 23, 30, SC, SE, VA & VS prefixes only) 10-2643 77 Lockbody ( 60, 63, 64 prefixes only) 10-2644 77 Lockbody ( 70, 72, 65-73, 65-73P lockbody) 10-3049 Outside rose spring assembly ( not finished) 10-0019...
  • Page 7 KP Series Keypad 10 Line Lock Parts Breakdown (Continued) A7113F • 800-810-WIRE (9473) • www.sargentlock.com...
  • Page 8: Installation Instructions

    KP Series Keypad 10 Line Lock Installation Instructions Step #1 – Verify Hand and Bevel of Door Stand on outside/locked side of door when determining the door hand LHRB RHRB Left Hand Left Hand Right Hand Right Hand Hinges Left Reverse Bevel Hinges Right Reverse Bevel...
  • Page 9 KP Series Keypad 10 Line Lock Step # 3 – Frame Preparation for Strike Step #4 Latch and Fire Stop Plate Installation 1. Install latch with beveled bolt facing the strike 2. Attach with two screws, but DO NOT tighten completely at this time 3.
  • Page 10 KP Series Keypad 10 Line Lock Step #5 – Install Lock Body Lock Preset to: • Through-bolt location– 12 & 6 o’clock • Door thickness– 1-3/4” thick- see below for other door conditions Adjustment for different through-bolt and door thickness: •...
  • Page 11 KP Series Keypad 10 Line Lock Step #6 - Securing the Lock to the Door If wood door, feed wires up through the routed channel as shown If metal door, feed wire connector within the door core and out hole on inside of door Attach inside rose assembly and spacer bushing and secure with screws shown How to Change Cylinder (if required)
  • Page 12 KP Series Keypad 10 Line Lock Step #7 – Install (Optional)* Weatherseal Gasket & Shroud 1. Carefully remove adhesive backing from the gasket (Fig. 5A). 2. Apply gasket to escutcheon: Peel back • Starting in one place, press the adhesive side of the gasket firmly against the escutcheon.
  • Page 13 KP Series Keypad 10 Line Lock Step #9 – Securing the Outside Escutcheon • From the inside of the door, use the #8-32 x 1 1/2” round head screw with the flat washer to attach the escutcheon thru the lower lug •...
  • Page 14 KP Series Keypad 10 Line Lock Step #11 – Securing Inside Escutcheon Remove black plastic battery cover with 1/8” security hex wrench • • Carefully tuck the wire into the routed groove in wood door. The remainder can fit within bottom portion of escutcheon.
  • Page 15 KP Series Keypad 10 Line Lock Step #13 – Battery Installation • Place (4) C batteries into the compartment as indicated inside escutcheon • Attach battery cover to inside escutcheon and secure with #8-32 x 3/8” security screw DO NOT OVERTIGHTEN Inside of door Outside of door How to Remove Outside Lever Only...
  • Page 16: Programming Instructions

    KP Series Keypad 10 Line Lock Programming Instructions The KP Keypad bored lock can support 99 users. Each user is assigned a User Number in addition to the code used for entry. Example: USER TYPE USER NUMBER USER CODE (2-6 DIGITS) Master 1 2 3 4 Emergency...
  • Page 17 KP Series Keypad 10 Line Lock Programming Instructions (Continued) All of the following procedures start with 99#. If after the last “ ” is depressed, the yellow LED does not go out, depress “ ” once more. Change Master Code: •...
  • Page 18 KP Series Keypad 10 Line Lock Programming Instructions (Continued) All of the following procedures start with 99# (continued). If after the last “ ” is depressed, the yellow LED does not go out, depress “*” once more. To Deactivate “Beep” With the Depression of Each Key: •...
  • Page 19 KP Series Keypad 10 Line Lock Programming Instructions (Continued) Chain Programming When programming multiple User Numbers and Codes into the Keypad Exit Device, it is not necessary to leave and re-enter the programming Mode (50) for each entry. Multiple entries may be chained together and the three different types of user codes (Standard, Passage and One time) may be mixed.
  • Page 20 KP Series Keypad 10 Line Lock Programming Instructions (Continued) All of the following procedures start with 99# (continued). If after the last “ *” is depressed, the yellow LED does not go out, depress “ *” once more. To Interrogate Transaction Log (to output last 15 entries): Hold Data Transfer Device (DTD) up to the (top right side) infrared LED as shown.
  • Page 21 KP Series Keypad 10 Line Lock Programming Instructions (Continued) To Delete a User Number: • Master Code* (Yellow LED Begins to Blink Slowly) • User Number# (Yellow LED Blinks Slowly) • * (Yellow LED Begins to Blink Quickly) • * (Yellow LED Blinks Slowly) •...
  • Page 22: Troubleshooting

    KP Series Keypad 10 Line Lock Troubleshooting Instructions Note: The following tests are used to check basic functionality of the keypad and inside controller. Power On Self Test (POST) for new KP controllers only (released after 1/2021) • Immediately after installing the batteries, verify the following keypad sequence: •...
  • Page 23 KP Series Keypad 10 Line Lock A7113F • 800-810-WIRE (9473) • www.sargentlock.com...
  • Page 24 The company’s customer base includes commercial construction, institutional, and industrial markets. Copyright © 2014. 2021, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
