6.2.2 Setting Commands

Command
>SetUpdateEdid
>SetInPortEdid [Param]
>GetInPortEdid
>SetHdcpActiveMode
[Param]
>GetHdcpActiveMode
>SetVideoOutput
Description
Upload user-defined EDID. The EDID DIP
switch must be set as "1111".
Set the EDID to [Param].
[
Param]=0~7.
0 - BYPASS
1 - 1920x1080@60 8bit Stereo
2 - 1920x1080@60 8bit High Definition
Audio
3 - 3840x2160@30Hz 8bit Stereo Audio
4 - 3840x2160@30Hz Deep Color High
Definition Audio
5 - 3840x2160@60Hz Deep Color Stereo
Audio
6 - 3840x2160@60Hz Deep Color HDR
LPCM 6CH
7 - USER EDID
The EDID DIP switch should be set as
"1111".
Get the EDID.
Set the HDCP active mode.
[Param]= Src, Sink
Src - Active by Src. Follow source.
Sink - Active by Sink. Follow display.
Note: The EDID switch must be switched to
"1111" before sending the command.
Get the HDCP active mode.
Enable or disable video output.
18
Command Example and
Feedback
<User edid ready,Please send
edid data in 10s.
<SetUpdateEdid_True/False
/
<Time out to send edid
>SetInPortEdid 0
<InPortEdid 0
<InPortEdid 0
>SetHdcpActiveMode Src
<HdcpActiveMode Src
<HdcpActiveMode Src
>SetVideoOutput 1,EN
