Now you are in the main view, where commands are sent and feedback is received.
The next step is to select the correct COM port of the PC. To do this, double-click on
"COM1" in the corresponding setup window.
In the following window, select the drop-down menu labeled "Send / Receive on Comm
Channel", select the appropriate COM port and then click on "OK" at the bottom right
corner.
All other settings can be left at default for most applications, but refer to device RS232
settings to be sure.
Double click on
"COM1" to change to
the right COM port.
