User Manual
PT-SP-HD116DA
3.2 Rear Panel
1
9
INPUT
1
① INPUT: Connect HDMI source.
② OUTPUTS: Total sixteen HDMI outputs to connect HDMI displays.
③ AUDIO OUT: Connect audio device (e.g. Amplifier) for audio de-embedding from
HDMI input.
④ RS232: Connect control device (e.g. PC) to control the splitter by sending RS232
commands.
⑤ DC 24V: DC connector for the power adapter connection.
OUTPUTS
2
3
4
10
11
12
2
5
6
7
13
14
15
9
4
8
RS232
AUDIO OUT
DC 24V
16
3
5
