- Page 1 GV600 User Manual GV600MG User Manual GPS Tracker QSZTRACGV600UM0106 Version: 1.06...
- Page 2 Document Control ID General Notes Queclink offers this information as a service to its customers, to support application and engineering efforts that use the products designed by Queclink. The information provided is based upon requirements specifically provided to Queclink by the customers. Queclink has not undertaken any independent search for additional relevant information, including any information that may be in the customer’s possession.
-
Page 3: Table Of Contents
2.1. GV600MG Products ......................3 2.2. Parts List ..........................3 2.3. Interface Definition ......................4 2.4. GV600MG Standard Cable Color ..................5 3. Getting Started ..........................6 3.1. Open and Close the Case ..................... 6 3.2. Install a SIM Card ......................... 7 3.3. - Page 4 Table 4. Parts List ..........................3 Table 5. Description of 18-pin Connections ..................4 Table 6. GV600MG Standard Cable Color Definition ..............5 Table 7. Electrical Characteristics of Ignition Detection ..............8 Table 8. Electrical Characteristics of the Digital Inputs ..............9 Table 9.
- Page 5 Figure Index Figure 1. The 18-pin Connector on the GV600MG............... 4 Figure 2. Open the Case ........................6 Figure 3. SIM Card Installation ......................7 Figure 4. Backup Battery Installation ....................7 Figure 5. External Power Supply Connection ..................8 Figure 6.
-
Page 6: Revision History
Initial 1.01 2017-05-12 Louis Wang Updating 1.02 2018-03-16 Arry Wang Delete cargo sensor 1.03 2018-08-22 Arry Wang Add 4G Product (GV600MG) 1.04 2018-10-09 Arry Wang Add function description 1.05 2019-02-14 Arry Wang Modified contents 1.06 2019-04-01 Arry Wang Modified contents... -
Page 7: Introduction
GV600MG User Manual 1. Introduction The GV600MG is a series of compact waterproof GPS trackers designed for a wide variety of vehicle tracking applications. They have multiple I/O interfaces that can be used for monitoring or controlling external devices, including a 1-wire interface used for temperature monitoring. -
Page 8: Product Overview
GV600MG User Manual 2. Product Overview 2.1. GV600ME Products Table 3. Product Model Model No. Region Technology Operating Band (MHz) GV608 Worldwide GSM/GPRS: 850/900/1800/1900 GSM/GPRS: 850/1900 North GV628W HSPA/UMTS/GSM HSPA/UMTS: 850(B5)/1900(B2) America GSM/GPRS: 850/900/1800/1900 HSPA/UMTS: GV648W Worldwide HSPA/UMTS/GSM 850(B5)/900(B8)/1900(B2)/2100(B1) LTE: B2/B4/B5/B12/B13/B25... -
Page 9: Interface Definition
GV600MG User Manual 2.3. Interface Definition The GV600MG Tracker has an 18-pin interface connector which contains the connections for power, I/O, TTL, etc. The sequence and definition of the 18-pin connector are shown in the following figure: Figure 1. The 18-pin Connector on the GV600MG Table 5. -
Page 10: Gv600Mg Standard Cable Color
GV600MG User Manual 2.4. GV600MG Standard Cable Color Table 6. GV600MG Standard Cable Color Definition Definition Color Pin No. Connector Pin No. Color Definition PWR1 Red/Green RWR2 AGNG Black Black AGNG White Green ADIN1 OUT-3V3 Red/White Black/White 1-WIRE Gray OUT/IN1... -
Page 11: Getting Started
GV600MG User Manual 3. Getting Started 3.1. Open and Close the Case Figure 2. Open the Case To open: Use a cross screwdriver to loosen the four screws and then lift the top case gently. To close: Align the top case with the bottom case and then tighten the four screws. -
Page 12: Install A Sim Card
SIM card is pushed into the SIM holder completely. Close the case. Figure 3. SIM Card Installation 3.3. Install the Internal Backup Battery GV600MG has an internal backup Li-ion battery (5800mAH). Figure 4. Backup Battery Installation QSZTRACGV600UM0106... -
Page 13: Power Supply Connection
GV600MG User Manual 3.4. Power Supply Connection PWR (pin 1 or pin 2)/GND (pin 3 or pin 4) are the power input pins. The input voltage range is from 8V to 32V. The device is designed to be installed in vehicles that operate on 12V or 24V systems without the need of external transformers. -
Page 14: Digital Inputs
GV600MG User Manual position of the vehicle ignition switch as shown above. An alternative to connect to the ignition switch is to find a non-permanent power source that is only available when the vehicle is running, for example, the power source for the FM radio. -
Page 15: Analogue Inputs
GV600MG User Manual 3.7. Analogue Inputs There is one analogue input on GV600MG, and the analogue input voltage range is from 0 to 32V. The following picture shows the recommended connection. Figure 8. Typical Analogue Input Connection Note: Pin 6 is a multifunction pin: it can be configured as an analogue input. - Page 16 GV600MG User Manual Figure 10. Typical Connection with a Relay Figure 11. Typical Connection with a LED Figure 12. Typical Connection with a Buzzer QSZTRACGV600UM0106...
-
Page 17: Device Status And Led
GV600MG User Manual Figure 13. Typical Connection with Other Devices Note: Pay attention to the polarity of the relay if it is pre-installed with an internal flyback diode during connection. Install an additional diode externally if there is no pre-installed internal diode. A common diode such as a 1N4004 one will work in most circumstances. -
Page 18: Temperature Sensor Interface
GV600ME User Manual Figure 14. GV600MG LEDs on the Case Note: 1. CELL LED cannot be configured. 2. GPS LED and PWR LED can be configured to turn off by using the configuration tool. 3. Fast flashing: for CELL LED is about 100ms ON/800ms OFF; for GPS LED and PWR LED is about 100ms ON/100ms OFF. - Page 19 GV600MG User Manual If the cable of temperature sensor has two wires, connect the temperature sensor to GV600 following the diagram and table as below: Figure 15. Typical Connection with a Temperature Sensor GV600 18-Pin Cable Color Description Temp Sensor...
-
Page 20: Serial Port/Uart Interface
GV600MG User Manual 3.11. Serial Port/UART Interface There are two lines dedicated to the Serial Port/UART interface (TXD and RXD). TXD and RXD are standard TTL signal. Figure 16. Typical Connection with USB to TTL Serial Port QSZTRACGV600UM0106... -
Page 21: Supported Peripheral List
GV600MG User Manual 4. Supported Peripheral List Name Description Temperature Sensor 1-Wire temperature sensor DS18B20 Digital RS232 (DUT-E COM Protocol) Fuel level Sensor Ultrasonic fuel level sensor UFS300 BLE 4.2 protocol supported Bluetooth Sensor iButton Supported (should be used with iButton reader)
