- Page 1 GV600MG Series User Manual GV600MG Series User Manual EGPRS/LTE Cat-M1/LTE NB1/GNSS Tracker QSZTRACGV600MGUM0101 Version: 1.01...
- Page 2 QSZTRACGV600MGUM0101 General Notes Queclink offers this information as a service to its customers, to support application and engineering efforts that use the products designed by Queclink. The information provided is based upon requirements specifically provided to Queclink by the customers. Queclink has not undertaken any independent search for additional relevant information, including any information that may be in the customer’s possession.
-
Page 3: Table Of Contents
2.2. LED Description ........................4 2.3. Parts List ..........................5 3. Interface Definition ........................6 4. GV600MG Series Device Cable Color .................... 7 5. Getting Started ..........................6 5.1. Opening and Closing the Case ..................... 6 5.2. Installing a SIM Card ......................6 5.3. -
Page 4: Revision History
GV600MG Series User Manual 0. Revision History Version Date Author Description of Change 1.00 2019-11-01 Arry Wang Initial 1.01 2020-06-28 Neal Lin Modify LEDs description QSZTRACGV600MGUM0101... -
Page 5: Introduction
Their built-in GPS receiver has superior sensitivity and fast initial positioning. Different models allow the GV600MG Series’ location to be monitored in real time or periodically tracked by a backend server and mobile devices. System integration is straightforward as complete documentation is provided for the full featured @Track protocol. -
Page 6: Product Overview
GV600MG Series User Manual 2. Product Overview 2.1. Product Appearance LEDs 18-pin Connector Figure 1. GV600MG Series Products View QSZTRACGV600MGUM0101... -
Page 7: Led Description
2.2. LED Description LEDs Figure 2. GV600MG Series LEDs There are three LEDs on GV800 Series. For details, please see the table below. Table 4. GV600MG Series LED Description Device Status LED Status Device is searching CELL network. Fast flashing (Note 3) Device has registered to CELL network. -
Page 8: Parts List
GV600MG Series User Manual 2.3. Parts List Table 5. GV600MG Series Parts List Name Picture Description EGPRS/LTE Cat-M1/LTE GV600MG Series Locator NB1/GNSS Tracker 135*62*38 mm GV600MG Series standard User Cable cable USB to TTL serial port USB Configure Cable (optional accessory) Power &... -
Page 9: Interface Definition
GV600MG Series User Manual 3. Interface Definition The GV600MG Series has an 18-pin interface connector which contains the connections for power, I/O, TTL, etc. The sequence and definition of the 18-pin connector are shown in the following figure: Figure 3. The 18-pin Connector on the GV600MG Series Table 6. -
Page 10: Gv600Mg Series Device Cable Color
GV600MG Series User Manual 4. GV600MG Series Device Cable Color Table 7. GV600MG Series Device Cable Color Definition Definition Color Pin No. Connector Pin No. Color Definition PWR1 Red/Green RWR2 AGNG Black Black AGNG White Green ADIN1 OUT-3V3 Red/White Black/White... -
Page 11: Getting Started
GV600MG Series User Manual 5. Getting Started 5.1. Opening and Closing the Case Figure 4. Open the Case To open: Use a cross screwdriver to loosen the screws and then lift the top case gently. To close: Align the top case with the bottom case and then tighten the screws. -
Page 12: Installing The Internal Backup Battery
GV600MG Series User Manual 5.3. Installing the Internal Backup Battery GV600MG Series has an internal backup Li-ion battery (5200mAH). Figure 6. Backup Battery Installation 5.4. Power Supply Connection PWR (pin 1 or pin 2)/GND (pin 3 or pin 4) are the power input pins. The input voltage range is from 8V to 32V. -
Page 13: Ignition Detection
GV600MG Series User Manual 5.5. Ignition Detection Table 8. Electrical Characteristics of Ignition Detection Logical Status Electrical Characteristics Active 5.0V to 32V Inactive 0V to 3V or open loop Figure 8. Typical Ignition Detection IGN (pin 5) is used for ignition detection. It is recommended to connect this pin to the “RUN”... -
Page 14: Digital Inputs
GV600MG Series User Manual 5.6. Digital Inputs There are four general purpose digital inputs on GV600MG. They all are negative triggers. Table 9. Electrical Characteristics of the Digital Inputs Logical Status Electrical Characteristics Active 0V to 0.8V Inactive Open loop The following picture shows the recommended connection of a digital input. -
Page 15: Analog Input
GV600MG Series User Manual 5.7. Analog Input There is one analogue input on GV600MG Series, and the analog input voltage range is from 0 to 32V. The following picture shows the recommended connection. Figure 10. Typical Analogue Input Connection Note: Pin 6 is a multifunction pin: it can be configured as an analogue input. - Page 16 GV600MG Series User Manual Figure 12. Typical Connection with a Relay Figure 13. Typical Connection with a LED Figure 14. Typical Connection with a Buzzer QSZTRACGV600MGUM0101...
-
Page 17: Temperature Sensor Interface
GV600MG Note: Please make sure to enable the “3.3V Output Enable” first in the Global Configuration in Manage Tool of GV600MG Series devices (refer to the images captured below), then this pin (pin 7) can output the corresponding voltage. QSZTRACGV600MGUM0101... - Page 18 GV600MG Series User Manual If the cable of temperature sensor has two wires, connect the temperature sensor to GV600MG following the diagram and table as below: Figure 16. Typical Connection with a Temperature Sensor GV600 18-Pin Cable Color Description...
-
Page 19: Serial Port/Uart Interface
GV600MG Series User Manual 5.10. Serial Port/UART Interface There are two lines dedicated to the Serial Port/UART interface (TXD and RXD). TXD and RXD are standard TTL signal. Figure 17. Typical Connection with USB to TTL Serial Port QSZTRACGV600MGUM0101... -
Page 20: Installation Precautions
GV600MG Series User Manual 6. Installation Precautions Firmly install the device to a reliable surface to prevent falling off. Make the side with antenna face sky to have better signal reception. Do not install the device under metal surface or in enclosed environments having difficulty in getting GPS and network signal. -
Page 21: Troubleshooting And Safety Info
GV600MG Series User Manual 7. Troubleshooting and Safety Info 7.1. Troubleshooting Table 11. GV600MG Series Troubleshooting List Problem Possible Reason Solution After the device is turned The signal is too weak. The Move the device to a place with device isn’t registered to the on, the CEL LED always good network coverage. -
Page 22: Appendix: Supported Accessories
GV600MG Series User Manual 8. Appendix: Supported Accessories Temperature Sensor (1-Wire temperature sensor DS18B20) Fuel level Sensor (Digital RS232 (DUT-E COM Protocol)/ Ultrasonic fuel level sensor UFS300) Bluetooth Sensor (BLE 4.2 protocol supported) iButton (Supported (should be used with iButton reader))
