1.6 Recommended PDUs and Available Installation Space
The following is a list of available PDU space that is recommended for use in each rack.
Table 4: Available PDU Space
Rack
EMCOR/CRENLO
AFCO/Legrand
APC/Schneider
TRIPP LITE w/ Rack
Extender
The following image displays the available zero space for mounting the PDU into the rack. This can be
used to size the PDU and related installation hardware outside of the hardware that is specified within this
document.

1.6 Recommended PDUs and Available Installation Space

Model
AS-160099-03
DC-42U2448-G
WEDIT602
WEDIT603
WEDIT604
WEDIT605
WEDIT606
AR3300
Rack:SR42UBDP
Extender: SREXTENDER
PDU Orientation
Rear Facing
Rear or Inward Facing
Rear Facing
Rear or Inward Facing
1. Overview
Space Available
W: 56mm x D: 190mm/
W: 2.2in. x D: 7.5in.
W: 67mm x D: 200mm/
W: 2.6in. x D: 7.9in.
W: 60mm x D: 113mm/
W: 2.4in. x D: 4.4in.
W: 60mm x D: 120mm/
W: 2.4in. x D: 4.7in.
8
