Computer SMART III FAST
Active alarms
4�6�2� TEST STATUS
This status is identified by the
The stages can be connected and disconnected manually, and the measured parameters that relate
to each one of the stages can be displayed. It also comprises the AutoTest function, which scans and
calculates all the stages of the unit.
A very long press (> 10s) of the
enter the Test status.
A very long press (> 10s) of the
the Measurement status.
Use keys and
If 5 minutes pass without any keys being pressed, the unit returns to the main screen.
Disconnection screen
Instruction Manual
symbol in the unit status area of the display (
key in any of the measurement screens causes the unit to
key in any of the test screens causes the unit to return to
to browse the various screens.
Parameters
Active alarm code E01 to E017
( )
Table 10
If there are more than 4 alarms, the information
is scrolled on the screen.
Parameters
Transition screen: used for the unit to disconnect
all the stages automatically before entering Test
status.
While in this screen, the unit does not respond
to the keys.
The unit automatically exits this screen, and this
can take a certain amount of time.
).
Figure 12
51
