Novatron Xsite EASY User Manual page 52

12 TROUBLESHOOTING
Symptom
Inaccurate measurement when
bucket tilting is used and tilt
axle is about perpendicular to
the Earth. See figure 64
Inaccurate measurement
Inaccurate measurement
Inoperative laser receiver
Inoperative laser receiver
Figure 64. Tilting axle is about perpendicular to the Earth
Possible cause
Inaccuracy is a due to the
physics of the gravitational
sensors.
Bucket is changed but correct
bucket is not being used by the
system
Calibration of the bucket has
not been performed correctly
The laser receiver is OFF
The laser receiver is broken or
lacks power.
No known solution.
Select the correct bucket, see
chapter 4.
Calibrate the bucket, see
chapter 5.2
Turn the laser receiver on, see
chapter 2.3.3
Contact local dealer or service.
Xsite EASY | User manual | Page 49 of 52
Action
