2.5 Detaching the laser receiver

It is recommended that the laser receiver is detached when it is not being used, for example when
carrying out work where there is a risk of damaging the laser receiver, such as dredging. When
removing the laser receiver, be sure to connect the detached cables together afterwards. Apply a
small amount of anti-corrosion gel or grease into the connector parts of the cables in order to
prevent water from getting into the connectors.
Figure 6. Laser receiver connected and bypassed
Caution
Always remember to put anti-corrosion gel or grease into the connectors (for
example SuperLube® Anti-Corrosion Gel).

2.6 Replacing a tilting bucket with a non-tilting bucket

Detach the cable going into the tilt bucket sensor, apply grease to the cable connector and attach a
plug to protect the connector.
Select the bucket that will be used from "Main menu" → "Buckets" and go to "Tilt calibration". The
first 1/7 page is for switching the tilt function ON or OFF. If the tilt function is ON, press the "0.0"
button to switch it OFF.
Caution
Always remember to put anti-corrosion gel or grease into the connectors (for
example SuperLube® Anti-Corrosion Gel).
