2.2 Switching the system ON/OFF

Excavator should be started up before turning Xsite Easy on. This procedure minimise power
spikes and results flawless operation. Turn the system ON by pressing the "Power" button (see
chapter 3.1). When the XD2 lightbar powers up, the LED on the bottom right corner blinks.
The system is turned OFF by pressing and holding the "Power" button for 3 seconds.
Sensors are equipped with internal heating. When the excavator is used in cold
temperatures, it takes time for the sensors to warm up and provide good accuracy.
Note
The amount of time needed between turning ON the Xsite EASY and starting the
work is shown in Table 1. Allow the proper warm-up time in order to ensure
accurate measurement results.
Table 1. Time needed to warm up the sensors in cold environment.
Temperature
-20°C
-10°C
-5°C

2.3 Display unit settings

The chapters below describe the different settings found under the display unit settings. See
chapter 3 for instructions on how to make changes to the settings.

2.3.1 Display brightness

The brightness of the display can be set in "Main menu" → "Display unit" → "Display" →
"Brightness". Choose between bright, medium and dim.

2.3.2 Sound settings

Sound settings can be adjusted in "Main menu" → "Display unit" → "Sounds". Select which of the
laser, target and button sounds are ON by pressing the "OK" button on the corresponding
selections. The volume can be switched between high, low and muted from the "Volume" menu.
Note
Warning level sounds are always ON, they can not be switched OFF.

2.3.3 Power button function

The function of the short press of the "Power" button can be adjusted in "Main menu" → "Display
unit" → "Buttons". Select either the possibility to switch the laser ON or OFF by pressing "OK" on
the "Laser" selection or select the possibility to use the memory function by pressing "OK" on the
"Memory" selection. The laser function is explained in chapter 6.3.1 and the memory function in
chapter 6.3.2.
Heating time
approx. 20 min
approx.10 min
approx. 5 min
Xsite EASY | User manual | Page 11 of 52
