Bucket tilting angle in degrees
Angle of the tilting bucket compared to horizontal level in degrees
Bucket tilting angle in percent
T%
Angle of the tilting bucket compared to horizontal level in percents
Machine roll in degrees
Angle of the side tilt of the cabin in degrees
R%
Machine roll in percent
Angle of the side tilt of the cabin in percents
Bucket angle in degrees
Angle of the bucket compared to the plumb line
Machine pitch in degrees
Angle of the forward and backward tilt of the cabin in degrees
P%
Machine pitch in percent
Angle of the forward and backward tilt of the cabin in percents
Digital clock
CL
Shows the time
CLa
Analogue clock
Traditional alternative to the digital clock
BFR
Bucket figure front view
Illustration of the bucket angle viewed from front
Slope percentage
S%
Slope percentage from the zeroed point to the bucket measuring point
Pitch angle for flat bucket or drill/pile attachment in degrees
Angle of the forward and backward tilt of the bucket in degrees
F%
Pitch angle for flat bucket or drill/pile attachment in percent
Angle of the forward and backward tilt of the bucket in percent
Roll angle for flat bucket or drill/pile attachment in degrees
Angle of the side tilt of the bucket in degrees
X%
Roll angle for flat bucket or drill/pile attachment in percent
Angle of the side tilt of the bucket in percents
Xsite EASY | User manual | Page 18 of 52
